D´AVINO DS 70 Specifications & Technical Data (2022-2026)

Technical specs - DS 70 D´AVINO

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.5 t

Standard tyres: 12.5/80-18 A6

Net load: 7 t

Dump capacity: 3.6 m³

Dumper type: D

Transport length: 4.282 m

Transport width: 1.91 m

Transport height: 2.78 m

Travel speed: 28 km/h

Loading height: 1.876 m

Engine manuf.: Yanmar

Engine type: k.A.

Engine power: 53.7 kW

No. of cylinders: 4

Emission level: V

More technical details, like: turning radius outside, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: No
Track: No
Aircondition: No

Download datasheets (PDF)

D´AVINO DS 70 FAQ

When was the Du00b4AVINO DS 70 manufactured?

The Du00b4AVINO DS 70 was first produced in 2022.

How much does the Du00b4AVINO DS 70 weigh?

The Du00b4AVINO DS 70 weighs 3.5 tons.

What are the transport dimensions of the Du00b4AVINO DS 70 wheel dumper?

The Du00b4AVINO DS 70 has transport dimensions of 4.28 meters in length, 1.91 meters in width, and 2.78 meters in height.

What is the travel speed of the Du00b4AVINO DS 70 wheel dumper?

The Du00b4AVINO DS 70 has a travel speed of 28 km/h.

What are the undercarriage tyre specifications of the Du00b4AVINO DS 70 wheel dumper?

The Du00b4AVINO DS 70 wheel dumper is equipped with standard tyres sized 12.5/80-18 A6.

What is the material handling capacity of the Du00b4AVINO DS 70 wheel dumper?

The Du00b4AVINO DS 70 wheel dumper has a net load capacity of 7 tons and a dump capacity of 3.6 cubic meters.

How much is a Du00b4AVINO DS 70 Wheel dumper (2022u20132025) worth?

The residual value of the Du00b4AVINO DS 70 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
