D 350 AHG Ausa D 350 AHG Specifications & Technical Data (2019—2026)

Weight: 2.831t – Standard tyres: 11.5/80-15.3 – Net load: 3.5t – Dump capacity: 2.13m³ – Dumper type: D – Transport length: 4.45m

D 350 AHG

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - D 350 AHG Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.831 t

Standard tyres: 11.5/80-15.3

Net load: 3.5 t

Dump capacity: 2.13 m³

Dumper type: D

Transport length: 4.45 m

Transport width: 1.84 m

Transport height: 2.77 m

Travel speed: 19 km/h

Loading height: 1.49 m

Turning radius outside: 4.515 m

Model series: AHG

Engine manuf.: Kubota

Engine type: D1803-CR-T-E5B

Engine power: 32.8 kW

Revolutions at max torque: 2400 rpm

Max. torque: 150.5/1500 Nm

No. of cylinders: 3

Emission level: V

More technical details, like: dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: Yes
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Ausa D 350 AHG FAQ

When was the Ausa D 350 AHG manufactured?

The Ausa D 350 AHG was first produced in 2019.

How much does the Ausa D 350 AHG wheel dumper weigh?

The Ausa D 350 AHG wheel dumper weighs 2.83 tons.

What are the transport dimensions of the Ausa D 350 AHG?

The Ausa D 350 AHG has a transport length of 4.45 meters, a transport width of 1.84 meters, and a transport height of 2.77 meters.

What is the travel speed of the Ausa D 350 AHG wheel dumper?

The Ausa D 350 AHG has a travel speed of 19 km/h.

What is the standard tyre size of the Ausa D 350 AHG?

The Ausa D 350 AHG has standard tyres sized 11.5/80-15.3.

What is the turning radius of the Ausa D 350 AHG wheel dumper?

The Ausa D 350 AHG has an outside turning radius of 4.515 meters.

What is the material handling capacity of the Ausa D 350 AHG wheel dumper?

The Ausa D 350 AHG has a net load capacity of 3.5 tons and a dump capacity of 2.13 cubic meters.

How much is a Ausa D 350 AHG Wheel dumper (2019u20132025) worth?

The residual value of the Ausa D 350 AHG depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
