Terex CR362LS Specifications & Technical Data (2008-2023)

Technical specs - CR362LS Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13.76 t

Transport length: 5.436 m

Transport width: 2.44 m

Transport height: 2.794 m

Standard width: 2.59 m

Max. width: 6.1 m

Drive: DE

Bunker capacity: 4.67 m³

Operating speed: 61 m/min

Type of screed: V

Engine manuf.: Cummins

Engine type: QSB4.5

Engine power: 119 kW

Revolutions at max torque: 2200 rpm

More technical details, like: hydr. extension from, hydr. extension up to, soil pressure, model series, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Vibration: No
High compaction: No
Spray unit: No
Tamper: No

Download datasheets (PDF)

CR362LS Terex Specification for North America (EN)

Terex CR362LS FAQ

When was the Terex CR362LS manufactured?

The Terex CR362LS was manufactured from 2008 until 2023.

How much does the Terex CR362LS weigh?

The Terex CR362LS weighs 13.76 tons.

What are the transport dimensions of the Terex CR362LS tracked asphalt paver?

The Terex CR362LS has a transport length of 5.44 meters, a transport width of 2.44 meters, and a transport height of 2.79 meters.

What is the operating speed of the Terex CR362LS tracked asphalt paver?

The Terex CR362LS has an operating speed of 61 meters per minute.

What type of drive system does the Terex CR362LS tracked asphalt paver have?

The Terex CR362LS tracked asphalt paver has a diesel electric drive system.

What are the paving performance specifications of the Terex CR362LS tracked asphalt paver?

The Terex CR362LS features a vibratory screed, a standard paving width of 2.59 meters, a maximum paving width of 6.1 meters, and an operating speed of 61 meters per minute.

How much is a Terex CR362LS Tracked Asphalt Paver (2008u20132023) worth?

The residual value of the Terex CR362LS depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
