Technical specs - HC 140i P Hamm
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 14.47 t
- Transport length
- 6.12 m
- Transport width
- 2.47 m
- Transport height
- 3.05 m
- Drive
- E
- Travel speed
- 11.9 km/h
- Roller width
- 2.14 m
- Rollers Ø
- 1.69 m
- Amplitude
- 1.9 mm
- Turning radius inside
- 4.131 m
- Statical line load
- 41.4 kg/cm
- Centrifugal force
- 290 kN
- Engine manuf.
- Isuzu
- Engine type
- AQ-6HK1X
- Engine power
- 119.6 kW
- Revolutions at max torque
- 2000 rpm
- No. of cylinders
- 4
- Emission level
- EU Stage V / EPA Tier 4
More technical details, like: vibration, frequency, turning radius outside, model series, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
Yes
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
Yes
