HC 130i VA Hamm HC 130i VA Specifications & Technical Data (2025—2026)

Weight: 13.565t – Transport length: 6.117m – Transport width: 2.474m – Transport height: 3.054m – Travel speed: 12.1km/h – Frequency: 30Hz

Rollers Single-drum Rollers Hamm HC 130i VA

Visit Hamm live at

Technical specs - HC 130i VA Hamm

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.565 t
Transport length
6.117 m
Transport width
2.474 m
Transport height
3.054 m
Travel speed
12.1 km/h
Frequency
30 Hz
Roller width
2.14 m
Rollers Ø
1.504 m
Amplitude
2.1 mm
Turning radius inside
4.131 m
Statical line load
38.32 kg/cm
Centrifugal force
320 kN
Model series
HC
Engine manuf.
Isuzu
Engine type
AQ-6HK1X
Engine power
119.6 kW
Revolutions at max torque
2000 rpm
No. of cylinders
4
Emission level
EU Stage V / EPA Tier 4

More technical details, like: vibration, drive, turning radius outside, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
Yes
Sheep foot
No
Oscillation
Yes
Compression control
No
Aircondition
No
