Caterpillar CS14 Specifications & Technical Data (2023-2026)

Technical specs - CS14 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 14.3 t

Travel speed: 11 km/h

Frequency: 30 Hz

Roller width: 2.13 m

Rollers Ø: 1.54 m

Amplitude: 2.1 mm

Turning radius inside: 3.6 m

Statical line load: 42.3 kg/cm

Centrifugal force: 301 kN

Engine manuf.: Caterpillar

Engine type: C4.4

Engine power: 117 kW

Displacement: 4.4 l

Emission level: EU V

More technical details, like: transport length, transport width, transport height, vibration, drive, turning radius outside, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: Yes
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: Yes

Caterpillar CS14 FAQ

When was the Caterpillar CS14 manufactured?

The Caterpillar CS14 was first produced in 2023.

How much does the Caterpillar CS14 weigh?

The Caterpillar CS14 weighs 14.3 tons.

What is the travel speed of the Caterpillar CS14 single-drum roller?

The Caterpillar CS14 has a travel speed of 11 km/h.

What is the inside turning radius of the Caterpillar CS14 single-drum roller?

The Caterpillar CS14 has an inside turning radius of 3.6 meters.

What are the compaction capabilities of the Caterpillar CS14 single-drum roller?

The Caterpillar CS14 operates at a frequency of 30 Hz with an amplitude of 2.1 mm, generates a centrifugal force of 301 kN, and has a statical line load of 42.3 kg/cm.

What are the roller specifications of the Caterpillar CS14 single-drum roller?

The Caterpillar CS14 has a roller width of 2.13 meters and a roller diameter of 1.54 meters.

How much is a Caterpillar CS14 Single-drum Roller (2023u20132025) worth?

The residual value of the Caterpillar CS14 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
