KOCKUM 565 Volvo KOCKUM 565 Specifications & Technical Data (1983—1986)
Visit Volvo live at
.jpg){kind=logo}
Technical specs - KOCKUM 565 Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 38.7 t
- Standard tyres
- 24.00-25
- Dump capacity
- 40.4 m³
- Net load
- 59 t
- Transport length
- 9.4 m
- Transport width
- 4.43 m
- Transport height
- 4.13 m
- Travel speed
- 64.5 km/h
- Turning radius outside
- 8.92 m
- Engine manuf.
- Detroit Diesel
- Engine type
- 16V71 TV70
- Engine power
- 496 kW
- Displacement
- 18.6 l
- Revolutions at max torque
- 2100 rpm
- Max. torque
- 2492 Nm
- No. of cylinders
- 16
- Cylinder bore x stroke
- 108x127 mm
More technical details, like: steering, loading height, model series, dimension lxwxh, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
No
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
Download datasheets (PDF)
Volvo KOCKUM 565 FAQ
How much does the Volvo KOCKUM 565 weigh?
What are the transport dimensions of the Volvo KOCKUM 565 rigid dump truck?
What is the travel speed of the Volvo KOCKUM 565 rigid dump truck?
What is the standard tyre size of the Volvo KOCKUM 565 rigid dump truck?
What is the outside turning radius of the Volvo KOCKUM 565 rigid dump truck?
What is the material handling capacity of the Volvo KOCKUM 565 rigid dump truck?
How much is a Volvo KOCKUM 565 Rigid dump truck (1983u20131986) worth?
