75476 Belaz 75476 Specifications & Technical Data (2018—2026)
Technical specs - 75476 Belaz
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 33.1 t
- Standard tyres
- 21.00-35 HC 36
- Dump capacity
- 27.6 m³
- Net load
- 45 t
- Steering
- VL
- Transport length
- 8.09 m
- Transport width
- 4.56 m
- Transport height
- 4.39 m
- Travel speed
- 50 km/h
- Turning radius outside
- 10.2 m
- Loading height
- 3.79 m
- Model series
- 7547
- Engine manuf.
- Kungur
- Engine type
- 550
- Engine power
- 410 kW
- Displacement
- 22.3 l
- Revolutions at max torque
- 1600 rpm
- Max. torque
- 2900 Nm
- No. of cylinders
- 12
- Cylinder bore x stroke
- 130x140 mm
More technical details, like: dimension lxwxh, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
No
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
