GR1003 XCMG GR1003 Specifications & Technical Data (2021—2026)

Weight: 7.5t – Standard tyres: 16/70-24/13.00-24 – Transport length: 7.13m – Transport width: 2.375m – Transport height: 3.15m – Mouldboard width: 3.048m

Graders XCMG GR1003
Graders XCMG GR1003
Graders XCMG GR1003
Graders XCMG GR1003

Visit XCMG live at

Technical specs - GR1003 XCMG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.5 t
Standard tyres
16/70-24/13.00-24
Transport length
7.13 m
Transport width
2.375 m
Transport height
3.15 m
Mouldboard width
3.048 m
Travel speed
38 km/h
Turning radius outside
6 m
Model series
GR
Engine manuf.
Weichai
Engine type
WP4.1
Engine power
75 kW
Revolutions at max torque
2200 rpm

More technical details, like: steering mode, drive, front blade width, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter
No
Bilateral levelling automatic
Yes
Front blade
No
Rear ripper
Yes
Aircondition
Yes

XCMG GR1003 FAQ

When was the XCMG GR1003 manufactured?

The XCMG GR1003 was first produced in 2021.

How much does the XCMG GR1003 grader weigh?

The XCMG GR1003 grader weighs 7.5 tons.

What are the transport dimensions of the XCMG GR1003 grader?

The XCMG GR1003 grader has a transport length of 7.13 meters, a transport width of 2.38 meters, and a transport height of 3.15 meters.

What is the travel speed of the XCMG GR1003 grader?

The XCMG GR1003 grader has a travel speed of 38 km/h.

What is the turning radius of the XCMG GR1003 grader?

The XCMG GR1003 grader has an outside turning radius of 6 meters.

How much is a XCMG GR1003 Grader (2021u20132025) worth?

The residual value of the XCMG GR1003 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
