PC360NLC-10 Komatsu excavator specs & Dimensions (2017 - 2020)

Komatsu PC360NLC-10 is a crawler excavator manufactured from 2017 to 2020. It has a weight of 35.49 tons and a track width of 600 …

Komatsu PC360NLC-10 is a crawler excavator manufactured from 2017 to 2020. It has a weight of 35.49 tons and a track width of 600 mm. The transport dimensions are 11.14 meters in length, 2.99 meters in width, and 3.28 meters in height. The machine features a tear-out force of 211.8 kN, a dredging depth of 7.38 meters, and a maximum horizontal reach of 10.92 meters. The bucket capacity is 2.47 cubic meters. Special equipment includes a diesel particulate filter and an overload alert system.

Crawler Excavators Komatsu PC360NLC-10
Crawler Excavators Komatsu PC360NLC-10
Crawler Excavators Komatsu PC360NLC-10
Crawler Excavators Komatsu PC360NLC-10
Crawler Excavators Komatsu PC360NLC-10
Crawler Excavators Komatsu PC360NLC-10

Visit Komatsu live at

Technical specs - PC360NLC-10 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
35.49 t
Transport length
11.14 m
Transport width
2.99 m
Transport height
3.28 m
Bucket capacity
2.47 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.92 m
Dredging depth
7.38 m
Tear-out force
211.8 kN
Model series
PC
Engine manuf.
Komatsu
Engine type
SAA6D114E-5
Engine power
192 kW
Displacement
8.85 l
No. of cylinders
6
Cylinder bore x stroke
114×144.5 mm
Emission level
IIIB

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh, revolutions at max torque, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu PC360NLC-10 FAQ

When was the Komatsu PC360NLC-10 manufactured?

The Komatsu PC360NLC-10 was manufactured from 2017 to 2020.

How much does the Komatsu PC360NLC-10 weigh?

The Komatsu PC360NLC-10 weighs 35.49 tons.

What are the transport dimensions of the Komatsu PC360NLC-10?

The Komatsu PC360NLC-10 has a transport length of 11.14 meters, a transport width of 2.99 meters, and a transport height of 3.28 meters.

What is the track width of the Komatsu PC360NLC-10's undercarriage?

The Komatsu PC360NLC-10 has a track width of 600 mm.

What are the excavation performance specifications of the Komatsu PC360NLC-10?

The Komatsu PC360NLC-10 has a dredging depth of 7.38 meters, a maximum horizontal reach of 10.92 meters, and is equipped with a monobloc boom.

What is the power rating of the Komatsu PC360NLC-10?

The source data does not provide power rating information for the Komatsu PC360NLC-10.

What is the bucket capacity of the Komatsu PC360NLC-10?

The Komatsu PC360NLC-10 has a bucket capacity of 2.47 cubic meters.

How much is a Komatsu PC360NLC-10 Crawler excavator (2017u20132020) worth?

The residual value of the Komatsu PC360NLC-10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
