PC350LCD-8 Komatsu excavator specs & Dimensions (2012 - 2013)

Komatsu PC350LCD-8 is a crawler excavator manufactured from 2012 to 2013, with a weight of 35 tons. It features a track width of 6…

Komatsu PC350LCD-8 is a crawler excavator manufactured from 2012 to 2013, with a weight of 35 tons. It features a track width of 600 mm, a transport length of 11.3 meters, a transport width of 3.2 meters, and a transport height of 3.1 meters. The machine has a tear-out force of 235 kN and comes equipped with air conditioning and an overload alert system.

Crawler Excavators Komatsu PC350LCD-8

Visit Komatsu live at

Technical specs - PC350LCD-8 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
35 t
Transport length
11.3 m
Transport width
3.2 m
Transport height
3.1 m
Bucket capacity
0.47 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
11.9 m
Dredging depth
8.18 m
Tear-out force
235 kN
Model series
PC
Engine manuf.
Komatsu
Engine type
SAA6D114E-3
Engine power
194 kW
Displacement
8.27 l
Revolutions at max torque
1950 rpm

More technical details, like: bucket capacity min., bucket capacity max., bucket width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Komatsu PC350LCD-8 FAQ

When was the Komatsu PC350LCD-8 manufactured?

The Komatsu PC350LCD-8 was manufactured from 2012 to 2013.

How much does the Komatsu PC350LCD-8 weigh?

The Komatsu PC350LCD-8 weighs 35 tons.

What are the transport dimensions of the Komatsu PC350LCD-8?

The Komatsu PC350LCD-8 has a transport length of 11.3 meters, a transport width of 3.2 meters, and a transport height of 3.1 meters.

What are the undercarriage specifications of the Komatsu PC350LCD-8?

The Komatsu PC350LCD-8 has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the Komatsu PC350LCD-8?

The Komatsu PC350LCD-8 has a dredging depth of 8.18 meters, a maximum horizontal reach of 11.9 meters, and is equipped with a Monobloc boom.

What are the power ratings of the Komatsu PC350LCD-8?

The source data does not provide any power rating information for the Komatsu PC350LCD-8.

What is the bucket capacity of the Komatsu PC350LCD-8?

The Komatsu PC350LCD-8 has a bucket capacity of 0.47 cubic meters.

How much is a Komatsu PC350LCD-8 Crawler excavator (2012u20132013) worth?

The residual value of the Komatsu PC350LCD-8 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
