PC350HD-8 Komatsu excavator specs & Dimensions (2010 - 2017)

Komatsu PC350HD-8 is a crawler excavator manufactured from 2010 to 2017. It has a weight of 40.266 tons and a track width of 900 m…

Komatsu PC350HD-8 is a crawler excavator manufactured from 2010 to 2017. It has a weight of 40.266 tons and a track width of 900 mm. The transport dimensions are 11.23 meters in length, 3.64 meters in width, and 3.2 meters in height. The excavator features a dredging depth of 8.1 meters and a maximum horizontal reach of 11.705 meters. The bucket width is 1.372 meters, with a bucket capacity of 1.96 cubic meters.

Crawler Excavators Komatsu PC350HD-8

Visit Komatsu live at

Technical specs - PC350HD-8 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
40.266 t
Transport length
11.23 m
Transport width
3.64 m
Transport height
3.2 m
Bucket capacity
1.96 m³
Undercarriage
HD
Track width
900 mm
Boom
MB
Max. Reach horizontal
11.705 m
Dredging depth
8.1 m
Bucket width
1.372 m
Model series
PC
Engine manuf.
Komatsu
Engine type
SAA6D114E-3
Engine power
194 kW
Displacement
8.27 l
Revolutions at max torque
1950 rpm
No. of cylinders
6
Cylinder bore x stroke
114x135 mm

More technical details, like: bucket capacity min., bucket capacity max., tear-out force, dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu PC350HD-8 FAQ

When was the Komatsu PC350HD-8 manufactured?

The Komatsu PC350HD-8 was manufactured from 2010 to 2017.

How much does the Komatsu PC350HD-8 weigh?

The Komatsu PC350HD-8 weighs 40.27 tons.

What are the transport dimensions of the Komatsu PC350HD-8?

The Komatsu PC350HD-8 has a transport length of 11.23 meters, a transport width of 3.64 meters, and a transport height of 3.2 meters.

What are the undercarriage specifications of the Komatsu PC350HD-8?

The Komatsu PC350HD-8 has a heavy duty undercarriage with a track width of 900 mm.

What are the excavation performance specifications of the Komatsu PC350HD-8?

The Komatsu PC350HD-8 has a dredging depth of 8.1 meters, a maximum horizontal reach of 11.705 meters, and is equipped with a monobloc boom.

What are the bucket specifications of the Komatsu PC350HD-8 excavator?

The Komatsu PC350HD-8 has a bucket capacity of 1.96 cubic meters and a bucket width of 1.372 meters.

How much is a Komatsu PC350HD-8 Crawler excavator (2010u20132017) worth?

The residual value of the Komatsu PC350HD-8 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
