H455S Komatsu excavator specs & Dimensions (1998 - 2005)

Komatsu H455S is a crawler excavator manufactured from 1998 to 2005. It has a weight of 490 tons and a track width of 1300 mm. The…

Komatsu H455S is a crawler excavator manufactured from 1998 to 2005. It has a weight of 490 tons and a track width of 1300 mm. The transport dimensions are 9.1 meters in length, 7.6 meters in width, and 8.74 meters in height. The excavator features a tear-out force of 1270 kN, a dredging depth of 8 meters, and a maximum horizontal reach of 15 meters. The bucket width is 4.4 meters, with a bucket capacity of 30 cubic meters.

Crawler Excavators Komatsu H455S

Visit Komatsu live at

Technical specs - H455S Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
490 t
Transport length
9.1 m
Transport width
7.6 m
Transport height
8.74 m
Bucket capacity
30 m³
Undercarriage
LCV
Track width
1300 mm
Boom
MB
Max. Reach horizontal
15 m
Dredging depth
8 m
Tear-out force
1270 kN
Bucket width
4.4 m
Model series
H
Engine manuf.
Komatsu
Engine type
KTTA38-C
Engine power
1680 kW
Displacement
38 l
Revolutions at max torque
1800 rpm
No. of cylinders
12
Cylinder bore x stroke
159x159 mm

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu H455S FAQ

When was the Komatsu H455S manufactured?

The Komatsu H455S was manufactured from 1998 to 2005.

How much does the Komatsu H455S weigh?

The Komatsu H455S weighs 490 tons.

What are the transport dimensions of the Komatsu H455S?

The Komatsu H455S has a transport length of 9.1 meters, a transport width of 7.6 meters, and a transport height of 8.74 meters.

What are the undercarriage specifications of the Komatsu H455S?

The Komatsu H455S has a long undercarriage that is hydraulically extendable and a track width of 1300 mm.

What are the excavation performance specifications of the Komatsu H455S?

The Komatsu H455S has a dredging depth of 8 meters, a maximum horizontal reach of 15 meters, and features a monobloc boom.

What is the tear-out force of the Komatsu H455S?

The Komatsu H455S has a tear-out force of 1270 kN.

What are the bucket specifications of the Komatsu H455S excavator?

The Komatsu H455S excavator has a bucket capacity of 30 cubic meters and a bucket width of 4.4 meters.

How much is a Komatsu H455S Crawler excavator (1998u20132005) worth?

The residual value of the Komatsu H455S depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Komatsu H455S overview

Hydraulic and electronic system

Diesel Drive

The powertrain consists of a main drive, gearbox, and six pumps which deliver hydraulic oil from the unpressurized hydraulic tank. Open-circuit hydraulics provide maximum cooling and filtering efficiency.


Cooling System

Large components provide superior engine cooling capacity. The hydraulic system includes a large vertical air-to-oil cooler with hydraulically driven fan. Hydraulic cooler is hinged and swings out for easy cleaning and maintenance.


Hydropilot

The Komatsu Demag Hydropilot 4-circuit hydraulic system features a load limiting governor with oil summation delivery to the working circuits and integral pressure cutoff. Hydropilot prioritizes hydraulic flow based on demand, allowing for smooth hydraulic response, simple hydraulic system layout, and a reduced number of components.


Cab

Cab

Fully adjustable weight-compensating seat with vibration-dampening and adjustable armrests. Foldaway auxiliary seat. Two levers control digging and swing functions. Foot pedals control all crawler motions, clam, and swing brake. External ROPS system. Air conditioner, heater/defogger, sound suppression, radio, sun visor, windshield wiper/washer. Cab is rubber-mounted to reduce noise and vibration.


Equipment

Boom/Stick & Bucket

Rigid box-section boom and stick offer exceptional service life for heavy-duty mining conditions. Large radius castings reinforce high stress areas. Oversized hydraulic cylinders provide heavy-duty performance and feature automatic lubricated bearings. Structural steel buckets with optional wear packages incorporate either Bofors or ESCO lips, mechanical shrouds, and tooth systems designed for various digging conditions.


Superstructure

Heavy-duty castings provide superior durability in high stress areas. Designed for excellent accessibility to major components for maintenance.
