JS370 LC JCB excavator specs & Dimensions (2022 - 2026)

JCB JS370 LC is a Crawler Excavator manufactured since 2022, with a weight of 36.142 tons. It features a track width of 600 mm, a …

JCB JS370 LC is a Crawler Excavator manufactured since 2022, with a weight of 36.142 tons. It features a track width of 600 mm, a transport length of 11.384 meters, a transport width of 3.2 meters, and a transport height of 3.61 meters. The machine has a dredging depth of 6.25 meters and a maximum horizontal reach of 9.85 meters. The bucket width is 1.8 meters, with a bucket capacity ranging from 0.86 cubic meters to 1.93 cubic meters.

Crawler Excavators JCB JS370 LC

Visit JCB live at

Technical specs - JS370 LC JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
36.142 t
Transport length
11.384 m
Transport width
3.2 m
Transport height
3.61 m
Bucket capacity min.
0.86 m³
Bucket capacity max.
1.93 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.85 m
Dredging depth
6.25 m
Bucket width
1.8 m
Model series
JS
Engine manuf.
JCB
Engine type
DieselMax 672
Engine power
210 kW
Displacement
7.2 l
No. of cylinders
6
Emission level
Tier 2

More technical details, like: bucket capacity, tear-out force, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

JCB JS370 LC FAQ

When was the JCB JS370 LC manufactured?

The JCB JS370 LC was first produced in 2022.

How much does the JCB JS370 LC weigh?

The JCB JS370 LC weighs 36.14 tons.

What are the transport dimensions of the JCB JS370 LC crawler excavator?

The JCB JS370 LC has a transport length of 11.38 meters, a transport width of 3.2 meters, and a transport height of 3.61 meters.

What are the undercarriage specifications of the JCB JS370 LC?

The JCB JS370 LC has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the JCB JS370 LC?

The JCB JS370 LC has a dredging depth of 6.25 meters, a maximum horizontal reach of 9.85 meters, and features a monobloc boom.

What are the bucket specifications of the JCB JS370 LC excavator?

The JCB JS370 LC excavator has a bucket width of 1.8 meters, with a capacity ranging from 0.86 to 1.93 cubic meters.

How much is a JCB JS370 LC Crawler excavator (2022u20132025) worth?

The residual value of the JCB JS370 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
