JCB 150X LC excavator specs (2021 - 2025)

Name: JCB 150X LC Crawler Excavators
Brand: JCB

JCB 150X LC is a Crawler Excavator manufactured since 2020, with a weight of 15.803 tons. It features a track width of 600 mm, a t…

JCB 150X LC is a Crawler Excavator manufactured since 2020, with a weight of 15.803 tons. It features a track width of 600 mm, a transport length of 7.89 meters, a transport width of 2.59 meters, and a transport height of 2.91 meters. The machine has a dredging depth of 6.02 meters and a maximum horizontal reach of 8.98 meters. The bucket width is 1.35 meters, with a capacity ranging from 0.21 to 0.89 cubic meters. Special equipment includes air conditioning and a diesel particulate filter.

150X LC

Years of manufacture: 2021—2025

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events & News

Technical specs - 150X LC JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15.803 t

Transport length: 7.89 m

Transport width: 2.59 m

Transport height: 2.91 m

Bucket capacity: 0.89 m³

Bucket capacity min.: 0.21 m³

Bucket capacity max.: 0.89 m³

Undercarriage: LC

Track width: 600 mm

Boom: VA

Max. Reach horizontal: 8.98 m

Dredging depth: 6.02 m

Bucket width: 1.35 m

Model series: X

Engine manuf.: JCB

Engine type: DieselMax

Engine power: 81 kW

Displacement: 4.8 l

Revolutions at max torque: 1450 rpm

No. of cylinders: 4

Emission level: V

More technical details, like: tear-out force, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter: Yes
Track adjustment: No
Blade: No
Cabin adjustment: No
Overload alert: Yes
Material Handling Excavator: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No
