    Wirtgen W 50 Specifications & Technical Data (2004-2015)

    Rate this machine now!

    Weight: 6.75t – Standard tyres: 560x203/560x254 – Cutting width: 500mm – Cutting depth: 160mm – Operating speed: 25m/min – Travel speed : 6km/h

    Technical specs - W 50 Wirtgen


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 6.75 t
    • Standard tyres 560x203/560x254
    • Cutting width 500 mm
    • Cutting depth 160 mm
    • Operating speed 25 m/min
    • Travel speed 6 km/h
    • Transport length 3.41 m
    • Transport width 1.34 m
    • Transport height 2.45 m
    • Engine manuf. Deutz
    • Engine type TD2011 L04w
    • Engine power 59.9 kW
    • Displacement 3.619 l
    • Track width ###
    • Turning radius outside ###
    • Dimension lxwxh ###
    • Revolutions at max torque ###
    • Max. torque ###
    • No. of cylinders ###
    • Cylinder bore x stroke ###
    • Emission level ###

    Basic model with cutting tools

    Special equipment

    • Diesel particulate filter
    • Cabin
    • Front loading conveyor
    • Infrared heater
    • Aircondition
