Sinoway SWMM500L
- Weight:
- 6.8 t
- Standard tyres:
- F: 559×203mm / R: 559×254mm
- Cutting width:
- 500 mm
- Cutting depth:
- 210 mm
SWMM500L Sinoway SWMM500L Specifications & Technical Data (2025—2026)
Technical specs - SWMM500L Sinoway
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 6.8 t
- Standard tyres
- F: 559×203mm / R: 559×254mm
- Cutting width
- 500 mm
- Cutting depth
- 210 mm
- Operating speed
- 40 m/min
- Travel speed
- 7.5 km/h
- Transport length
- 3.7 m
- Transport width
- 1.888 m
- Transport height
- 2.53 m
- Model series
- SWMM
- Engine manuf.
- SDEC
- Engine type
- N/a
- Engine power
- 92 kW
- Displacement
- 4.3 l
- Emission level
- CN III
More technical details, like: track width, turning radius outside, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with cutting tools
Special equipment
- Diesel particulate filter
-
No
- Cabin
-
No
- Front loading conveyor
-
No
- Infrared heater
-
No
- Aircondition
-
No
