D5R2 LGP Caterpillar D5R2 LGP Specifications & Technical Data (2019—2026)

Weight: 18.5t – Transport length: 4.02m – Transport width: 3.28m – Transport height: 3.2m – Travel speed: 10.1km/h – Reverse travel speed: 12.5km/h

D5R2 LGP

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D5R2 LGP Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 18.5 t

Transport length: 4.02 m

Transport width: 3.28 m

Transport height: 3.2 m

Travel speed: 10.1 km/h

Reverse travel speed: 12.5 km/h

Front blade width: 4.08 m

Model series: D

Engine manuf.: Caterpillar

Engine type: C7.1 Acert

Engine power: 114 kW

Displacement: 7.1 l

Cylinder bore x stroke: 105x135 mm

Emission level: Tier 3/ IIIA

More technical details, like: blade type, soil pressure, track width, transmission type, max. drawbar pull, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin and corresponding blade

Special equipment

Diesel particulate filter: No
Rear ripper: No
Tilt device: No
Aircondition: Yes

Download specalog and datasheets (PDF)

D5R2 LGP Caterpillar Specification for Europe (EN)

Caterpillar D5R2 LGP FAQ

When was the Caterpillar D5R2 LGP manufactured?

The Caterpillar D5R2 LGP was first produced in 2019.

How much does the Caterpillar D5R2 LGP weigh?

The Caterpillar D5R2 LGP weighs 18.5 tons.

What are the transport dimensions of the Caterpillar D5R2 LGP bulldozer?

The Caterpillar D5R2 LGP bulldozer has a transport length of 4.02 meters, a transport width of 3.28 meters, and a transport height of 3.2 meters.

What are the travel speeds of the Caterpillar D5R2 LGP bulldozer?

The Caterpillar D5R2 LGP bulldozer has a travel speed of 10.1 km/h forward and 12.5 km/h in reverse.

What is the width of the front blade on the Caterpillar D5R2 LGP bulldozer?

The front blade of the Caterpillar D5R2 LGP bulldozer is 4.08 meters wide.
