ZD160-3 Zoomlion ZD160-3 Specifications & Technical Data (2017—2026)
Technical specs - ZD160-3 Zoomlion
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 16.5 t
- Transport length
- 5.05 m
- Transport width
- 3.416 m
- Transport height
- 3.2 m
- Blade type
- B
- Soil pressure
- 0.67 kg/cm²
- Track width
- 510 mm
- Travel speed
- 10.6 km/h
- Reverse travel speed
- 13.6 km/h
- Front blade width
- 3.416 m
- max. Drawbar Pull
- 15.5 t
- Model series
- ZD
- Engine manuf.
- Weichai
- Engine type
- WD10G178E25
- Engine power
- 131 kW
- Dimension lxwxh
- 1700x1100x1800 mm
- Displacement
- 9.715 l
- Revolutions at max torque
- 1100 rpm
- Max. torque
- 830 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 126x130 mm
- Emission level
- Euro II
Basic model with ROPS cabin and corresponding blade
Special equipment
- Diesel particulate filter
-
No
- Rear ripper
-
No
- Tilt device
-
No
- Aircondition
-
No
