PB 50 Palazzani PB 50 Specifications & Technical Data (1997—2004)

The Palazzani PB 50 Backhoe Loader, manufactured from 1997 to 2004, is a construction machine with a weight of 5.5 tons. It has a …

The Palazzani PB 50 Backhoe Loader, manufactured from 1997 to 2004, is a construction machine with a weight of 5.5 tons. It has a transport length of 5.08 meters, a bucket capacity of 0.75 cubic meters, a transport width of 1.9 meters, and a transport height of 3.08 meters. This machine is equipped with a grabber and outrigger stabilizers.

PB 50

Years of manufacture: 1997—2004

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PB 50 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.5 t

Standard tyres: 12.5x18

Bucket capacity: 0.75 m³

Drive: A

Transport length: 5.08 m

Transport width: 1.9 m

Transport height: 3.08 m

Model series: PB

Engine manuf.: Perkins

Engine type: 704.30

Engine power: 47 kW

More technical details, like: bucket width, bucket capacity backhoe, tear-out force, tear-out force backhoe, max. reach horizontal, dredging depth, max. discharge height, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, backhoe type, engine manufacturer, engine model, aspiration, rated speed, engine output - net, engine output - gross, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, ground clearance, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, reach from slew pivot - non-extending dipper, loading height - non-extending dipper, dump height - general purpose, fuel tank, shovel capacity - standard general purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: No
Forklift utility: No
Grabber: Yes
Diesel particulate filter: No
Aircondition: No

Palazzani PB 50 FAQ

When was the Palazzani PB 50 manufactured?

The Palazzani PB 50 was manufactured from 1997 to 2004.

How much does the Palazzani PB 50 backhoe loader weigh?

The Palazzani PB 50 backhoe loader weighs 5.5 tons.

What are the transport dimensions of the Palazzani PB 50 backhoe loader?

The Palazzani PB 50 has a transport length of 5.08 meters, a transport width of 1.9 meters, and a transport height of 3.08 meters.

What are the undercarriage specifications of the Palazzani PB 50 backhoe loader?

The Palazzani PB 50 features an all-wheel drive system and comes equipped with standard tyres sized 12.5x18.

What is the bucket capacity of the Palazzani PB 50 backhoe loader?

The Palazzani PB 50 backhoe loader has a bucket capacity of 0.75 cubic meters.

How much is a Palazzani PB 50 Backhoe loader (1997u20132004) worth?

The residual value of the Palazzani PB 50 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
