AL 8 D Ahlmann AL 8 D Specifications & Technical Data (1993—1997)

Model rating: 8,67 / 10

The Ahlmann AL 8 D is a backhoe loader manufactured by Ahlmann from 1993 to 1997. It has a weight of 6.3 tons and a transport leng…

The Ahlmann AL 8 D is a backhoe loader manufactured by Ahlmann from 1993 to 1997. It has a weight of 6.3 tons and a transport length of 4.86 meters. The bucket capacity is 0.8 cubic meters, with a tear-out force of 40 kilonewtons. It can dredge up to a depth of 3.5 meters and has a maximum discharge height and reach horizontal of 3.5 meters and 4.5 meters respectively. The transport width is 1.85 meters and the transport height is 2.65 meters. This construction machine is equipped with a clamshell as its special equipment.

AL 8 D

Years of manufacture: 1993—1997

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AL 8 D Ahlmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.3 t

Standard tyres: 365/70 R18

Bucket capacity: 0.8 m³

Drive: A

Transport length: 4.86 m

Transport width: 1.85 m

Transport height: 2.65 m

Tear-out force: 40 kN

Max. Reach horizontal: 4.5 m

Dredging depth: 3.5 m

Max. discharge height: 3.5 m

Model series: AL

Engine manuf.: Deutz

Engine type: BF4L1011F

Engine power: 44 kW

Revolutions at max torque: 2300 rpm

More technical details, like: bucket width, bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, engine model, aspiration, rated speed, engine output - net, transmission type, tyre - size, service brake - type, service brake - location, wheelbase, length - shovel on ground, height - over cab, ground clearance, width - over tyres, shovel - type, shovel - width, full lift dump height, full lift reach, loader - arm type, loader - geometry, dump angle - at dump, dump angle - maximum, full lift dump height - maximum, height - maximum, turning radius - over shovel, heaped capacity, straight tipping load, full turn tipping load, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: Yes
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

AL 8 D Ahlmann Specification for Europe (DE, EN, FR)

Ahlmann AL 8 D FAQ

When was the Ahlmann AL 8 D manufactured?

The Ahlmann AL 8 D was manufactured from 1993 to 1997.

How much does the Ahlmann AL 8 D weigh?

The Ahlmann AL 8 D weighs 6.3 tons.

What are the transport dimensions of the Ahlmann AL 8 D backhoe loader?

The Ahlmann AL 8 D has a transport length of 4.86 meters, a transport width of 1.85 meters, and a transport height of 2.65 meters.

What are the undercarriage specifications of the Ahlmann AL 8 D backhoe loader?

The Ahlmann AL 8 D backhoe loader has an all-wheel drive system and is equipped with standard tyres sized 365/70 R18.

What are the excavation performance specifications of the Ahlmann AL 8 D backhoe loader?

The Ahlmann AL 8 D has a dredging depth of 3.5 meters and a maximum horizontal reach of 4.5 meters.

What is the tear-out force of the Ahlmann AL 8 D backhoe loader?

The Ahlmann AL 8 D has a tear-out force of 40 kN.

What is the material handling capacity of the Ahlmann AL 8 D in terms of maximum discharge height?

The Ahlmann AL 8 D has a maximum discharge height of 3.5 meters.

What is the bucket capacity of the Ahlmann AL 8 D backhoe loader?

The bucket capacity of the Ahlmann AL 8 D backhoe loader is 0.8 cubic meters.
