Technical specs - 310L John Deere Construction
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.
- Weight 6.65 t
- Standard tyres F:12.5/80-18 F3 (12) R: 19.5-24 R4 (12)
- Bucket width 2.18 m
- Bucket capacity 0.77 m³
- Bucket capacity backhoe 0.18 m³
- Drive A
- Transport length 7.24 m
- Transport width 2.18 m
- Transport height 2.81 m
- Tear-out force 41.6 kN
- Tear-out force backhoe 48.2 kN
- Max. Reach horizontal 5.42 m
- Dredging depth 4.3 m
- Max. discharge height 2.74 m
- Travel speed 33.9 km/h
- Model series L
- Engine manuf. John Deere
- Engine type 4045HT096
- Engine power 69 kW
- Displacement 4.5 l
- Revolutions at max torque 2244 rpm
- Max. torque 383/1400 Nm
- No. of cylinders 4
- Emission level Tier 4/EU IV
More technical details, like: average fuel consumption, fuel consumption range (min - max), dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
- Clamshell
- Forklift utility
- Grabber
- Diesel particulate filter
- Aircondition
