410 E John Deere Construction 410 E Specifications & Technical Data (1997—2021)
Technical specs - 410 E John Deere Construction
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 6.804 t
- Standard tyres
- F: 111-1 6. T2 PR F3 R: 19.5L-24. 10 PR R4
- Bucket width
- 2.34 m
- Bucket capacity
- 1 m³
- Bucket capacity backhoe
- 0.21 m³
- Transport length
- 7.29 m
- Transport width
- 2.18 m
- Transport height
- 3.94 m
- Tear-out force
- 45.8 kN
- Tear-out force backhoe
- 65.8 kN
- Max. Reach horizontal
- 8.33 m
- Dredging depth
- 6.1 m
- Max. discharge height
- 4.72 m
- Travel speed
- 43.8 km/h
- Model series
- E
- Engine manuf.
- John Deere
- Engine type
- 4045T
- Engine power
- 73 kW
- Displacement
- 4.524 l
- Max. torque
- 389 Nm
- No. of cylinders
- 4
More technical details, like: drive, dimension lxwxh, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
Yes
- Clamshell
-
No
- Forklift utility
-
Yes
- Grabber
-
No
- Diesel particulate filter
-
Yes
- Aircondition
-
No
Download datasheets (PDF)
John Deere Construction 410 E FAQ
How much does the John Deere Construction 410 E backhoe loader weigh?
What are the transport dimensions of the John Deere Construction 410 E backhoe loader?
What is the travel speed of the John Deere Construction 410 E backhoe loader?
What are the standard undercarriage tyre specifications for the John Deere Construction 410 E backhoe loader?
What are the dredging depth and maximum horizontal reach of the John Deere Construction 410 E backhoe loader?
What are the tear-out forces of the John Deere Construction 410 E?
What is the maximum discharge height of the John Deere Construction 410 E backhoe loader?
What are the bucket specifications of the John Deere Construction 410 E backhoe loader?
How much is a John Deere Construction 410 E Backhoe loader (1997u20132021) worth?
