3CX Eco JCB 3CX Eco Specifications & Technical Data (2009—2017)

The JCB 3CX Eco is a backhoe loader manufactured by JCB from 2009 to 2017. It weighs 8.1 tons and has a transport length of 5.62 m…

The JCB 3CX Eco is a backhoe loader manufactured by JCB from 2009 to 2017. It weighs 8.1 tons and has a transport length of 5.62 meters. The bucket capacity is 1.1 cubic meters, with a dredging depth of 4.37 meters and a bucket width of 2.35 meters. The maximum discharge height is 2.74 meters, and it has a maximum reach horizontal of 5.37 meters. The transport width is 2.35 meters, and the transport height is 3.61 meters.

Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco
Backhoe Loaders JCB 3CX Eco

Visit JCB live at

Technical specs - 3CX Eco JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.1 t
Standard tyres
16 x 20. 10PR/18.4 x 26. 12PR
Bucket width
2.35 m
Bucket capacity
1.1 m³
Drive
A
Transport length
5.62 m
Transport width
2.35 m
Transport height
3.61 m
Tear-out force
52.8 kN
Max. Reach horizontal
5.37 m
Dredging depth
4.37 m
Max. discharge height
2.74 m
Model series
CX
Engine manuf.
JCB
Engine type
444
Engine power
81 kW
Displacement
4.4 l
Revolutions at max torque
1300 rpm
Max. torque
516 Nm
No. of cylinders
4
Cylinder bore x stroke
103x132 mm

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

JCB 3CX Eco FAQ

When was the JCB 3CX Eco manufactured?

The JCB 3CX Eco was manufactured from 2009 to 2017.

How much does the JCB 3CX Eco weigh?

The JCB 3CX Eco weighs 8.1 tons.

What are the transport dimensions of the JCB 3CX Eco backhoe loader?

The JCB 3CX Eco has a transport length of 5.62 meters, a transport width of 2.35 meters, and a transport height of 3.61 meters.

What are the undercarriage specifications of the JCB 3CX Eco backhoe loader?

The JCB 3CX Eco features an all-wheel drive system and standard tyres sized 16 x 20. 10PR and 18.4 x 26. 12PR.

What are the excavation performance specifications of the JCB 3CX Eco backhoe loader?

The JCB 3CX Eco has a dredging depth of 4.37 meters and a maximum horizontal reach of 5.37 meters.

What is the tear-out force of the JCB 3CX Eco backhoe loader?

The JCB 3CX Eco backhoe loader has a tear-out force of 52.8 kN.

What is the maximum discharge height of the JCB 3CX Eco backhoe loader?

The JCB 3CX Eco backhoe loader has a maximum discharge height of 2.74 meters.

What are the specifications of the primary work tool bucket on the JCB 3CX Eco?

The primary work tool bucket of the JCB 3CX Eco has a capacity of 1.1 cubic meters and a width of 2.35 meters.

How much is a JCB 3CX Eco Backhoe loader (2009u20132017) worth?

The residual value of the JCB 3CX Eco depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
