Technical specs - 3CX Compact Plus JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 6 t
- Standard tyres
- 12.5x18-10
- Bucket width
- 2 m
- Bucket capacity
- 1 m³
- Drive
- A
- Transport length
- 5.52 m
- Transport width
- 2 m
- Transport height
- 3.08 m
- Max. Reach horizontal
- 4.6 m
- Dredging depth
- 3.38 m
- Max. discharge height
- 2.35 m
- Travel speed
- 40 km/h
- Engine manuf.
- Kohler
- Engine type
- k.A.
- Engine power
- 55 kW
- Displacement
- 2.483 l
- Revolutions at max torque
- 2200 rpm
- Max. torque
- 330 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 88x102 mm
- Emission level
- V
More technical details, like: bucket capacity backhoe, tear-out force, tear-out force backhoe, model series, dimension lxwxh are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
Yes
- Clamshell
-
No
- Forklift utility
-
No
- Grabber
-
No
- Diesel particulate filter
-
Yes
- Aircondition
-
No
Download datasheets (PDF)
