210 SL JCB 210 SL Specifications & Technical Data (1997—2004)

The JCB 210 SL Backhoe Loader, manufactured from 1997 to 2004, weighs 5.571 tons and has a transport length of 4.88 meters. It has…

The JCB 210 SL Backhoe Loader, manufactured from 1997 to 2004, weighs 5.571 tons and has a transport length of 4.88 meters. It has a bucket capacity of 0.06 cubic meters and a dredging depth of 3.65 meters. The bucket width is 1.22 meters, and it can reach a maximum discharge height of 4.41 meters. With a maximum horizontal reach of 5.51 meters, it has a transport width of 1.85 meters and a transport height of 2.55 meters.

Backhoe Loaders JCB 210 SL

Visit JCB live at

Technical specs - 210 SL JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.571 t
Standard tyres
12.5x18.1PR
Bucket width
1.22 m
Bucket capacity
0.06 m³
Drive
A
Transport length
4.88 m
Transport width
1.85 m
Transport height
2.55 m
Max. Reach horizontal
5.51 m
Dredging depth
3.65 m
Max. discharge height
4.41 m
Engine manuf.
Perkins
Engine type
1000
Engine power
48.5 kW
Displacement
4 l
Revolutions at max torque
2000 rpm
Max. torque
228 Nm
No. of cylinders
4
Cylinder bore x stroke
100x127 mm

More technical details, like: bucket capacity backhoe, tear-out force, tear-out force backhoe, travel speed, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

JCB 210 SL FAQ

When was the JCB 210 SL manufactured?

The JCB 210 SL was manufactured from 1997 to 2004.

How much does the JCB 210 SL backhoe loader weigh?

The JCB 210 SL backhoe loader weighs 5.57 tons.

What are the transport dimensions of the JCB 210 SL backhoe loader?

The JCB 210 SL has a transport length of 4.88 meters, a transport width of 1.85 meters, and a transport height of 2.55 meters.

What are the undercarriage specifications of the JCB 210 SL backhoe loader?

The JCB 210 SL backhoe loader has an all-wheel drive system and is equipped with standard tyres sized 12.5x18.1PR.

What are the excavation performance specifications of the JCB 210 SL backhoe loader?

The JCB 210 SL has a dredging depth of 3.65 meters and a maximum horizontal reach of 5.51 meters.

What is the maximum discharge height of the JCB 210 SL?

The JCB 210 SL has a maximum discharge height of 4.41 meters.

What are the specifications of the bucket on the JCB 210 SL backhoe loader?

The JCB 210 SL backhoe loader has a bucket capacity of 0.06 cubic meters and a bucket width of 1.22 meters.

How much is a JCB 210 SL Backhoe loader (1997u20132004) worth?

The residual value of the JCB 210 SL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
