A30C 6x6 Volvo A30C 6x6 Specifications & Technical Data (1998—2002)

Model rating
8,00 / 10

The A 30 C 6x6 articulated dump truck model is manufactured by Volvo. Find and download detailed specs and data sheets for this ma…

The A 30 C 6x6 articulated dump truck model is manufactured by Volvo. Find and download detailed specs and data sheets for this machine here.

This articulated dump truck is built to provide up to 232kW or 311 horse power, delivered from its powerful Volvo engine to the 21.5t A 30 C 6x6 machine. This Volvo articulated dump truck belongs to the medium sized machine segment in the articulated dump trucks category.

Tailgate, Central lubrication and Aircondition are not provided on this model as of 2002. There are more detailed specifications and machine descriptions available in the original Volvo A 30 C 6x6 specs data sheet. Available in German and English, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

This model can be acquired for a list price between €307000 and €391000. Production of the A 30 C 6x6 stopped in 2002. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, 9 other articulated dump trucks, which range from 22.5t up to 43.8t are produced by Volvo. Of these, A 60 H, A 40 G and also A 30 G are the most frequently visited on LECTURA Specs. Currently, 9 models of the A 30 C 6x6 articulated dump truck exist, at an average sale value of €32600 at 17 years of age. Want more detailed specifications? Download the latest Volvo A 30 C 6x6 specs data sheet on LECTURA Specs today!

Articulated Dump Trucks Volvo A30C 6x6

Visit Volvo live at

Technical specs - A30C 6x6 Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.5 t
Standard tyres
30/65 R 25
Dump capacity
16.5 m³
Net load
27 t
Model series
A
Engine manuf.
Volvo
Engine type
TD104KAE
Engine power
232 kW

More technical details, like: travel speed, transport length, transport width, transport height, turning radius outside, loading height, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Diesel particulate filter
No
Central lubrication
No
Heated dump body
No
Tailgate
No
Aircondition
No

Download datasheets (PDF)

Volvo A30C 6x6 FAQ

When was the Volvo A30C 6x6 manufactured?

The Volvo A30C 6x6 was manufactured from 1998 to 2002.

How much does the Volvo A30C 6x6 weigh?

The Volvo A30C 6x6 weighs 21.5 tons.

What are the undercarriage specifications of the Volvo A30C 6x6?

The Volvo A30C 6x6 is equipped with standard tyres sized 30/65 R 25.

What is the material handling capacity of the Volvo A30C 6x6 articulated dump truck?

The Volvo A30C 6x6 has a net load capacity of 27 tons and a dump capacity of 16.5 cubic meters.

How much is a Volvo A30C 6x6 Articulated dump truck (1998u20132002) worth?

The residual value of the Volvo A30C 6x6 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
