735-04A Caterpillar 735-04A Specifications & Technical Data (2019—2026)
Technical specs - 735-04A Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 25.2 t
- Standard tyres
- 750/65 R25
- Dump capacity
- 20 m³
- Travel speed
- 57 km/h
- Net load
- 32 t
- Transport length
- 11.06 m
- Transport width
- 4.17 m
- Transport height
- 4 m
- Turning radius outside
- 8.42 m
- Loading height
- 2.99 m
- Engine manuf.
- Caterpillar
- Engine type
- C13 Acert
- Engine power
- 320 kW
- Displacement
- 12.5 l
- Revolutions at max torque
- 1200 rpm
- Max. torque
- 2618 Nm
- Cylinder bore x stroke
- 137x171.5 mm
- Emission level
- U.S. EPA Tier 4 Final/EU V
More technical details, like: model series, dimension lxwxh, no. of cylinders are available in the full technical specs.
Special equipment
- Diesel particulate filter
-
Yes
- Central lubrication
-
Yes
- Heated dump body
-
Yes
- Tailgate
-
No
- Aircondition
-
Yes
Download specalog and datasheets (PDF)
