730 EJ Caterpillar 730 EJ Specifications & Technical Data (2019—2026)

Weight: 26.21t – Standard tyres: 750/65 R25 – Dump capacity: 16.9m³ – Travel speed: 55km/h – Net load: 27.1t – Transport length: 10.376m

Articulated Dump Trucks Caterpillar 730 EJ

730 EJ

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 730 EJ Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 26.21 t

Standard tyres: 750/65 R25

Dump capacity: 16.9 m³

Travel speed: 55 km/h

Net load: 27.1 t

Transport length: 10.376 m

Transport width: 3.013 m

Transport height: 3.751 m

Turning radius outside: 7.47 m

Loading height: 3.027 m

Engine manuf.: Caterpillar

Engine type: C13 Acert

Engine power: 276 kW

Displacement: 12.5 l

Revolutions at max torque: 1200 rpm

Max. torque: 1810 Nm

Cylinder bore x stroke: 130x157 mm

Emission level: U.S. EPA Tier 2/EU II / U.S. EPA Tier 3/EU IIIA

More technical details, like: model series, dimension lxwxh, no. of cylinders are available in the full technical specs.

Special equipment

Diesel particulate filter: No
Central lubrication: No
Heated dump body: No
Tailgate: No
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar 730 EJ FAQ

When was the Caterpillar 730 EJ manufactured?

The Caterpillar 730 EJ was first produced in 2019.

How much does the Caterpillar 730 EJ weigh?

The Caterpillar 730 EJ weighs 26.21 tons.

What are the transport dimensions of the Caterpillar 730 EJ articulated dump truck?

The Caterpillar 730 EJ has a transport length of 10.38 meters, a transport width of 3.01 meters, and a transport height of 3.75 meters.

What is the travel speed of the Caterpillar 730 EJ articulated dump truck?

The Caterpillar 730 EJ has a travel speed of 55 km/h.

What is the standard tyre size of the Caterpillar 730 EJ?

The Caterpillar 730 EJ is equipped with standard tyres of size 750/65 R25.

What is the turning radius of the Caterpillar 730 EJ articulated dump truck?

The Caterpillar 730 EJ has an outside turning radius of 7.47 meters.

What is the material handling capacity of the Caterpillar 730 EJ articulated dump truck?

The Caterpillar 730 EJ has a net load capacity of 27.1 tons, a dump capacity of 16.9 cubic meters, and a loading height of 3.03 meters.

How much is a Caterpillar 730 EJ Articulated dump truck (2019u20132025) worth?

The residual value of the Caterpillar 730 EJ depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
