Dominator 66 Claas Dominator 66 Specifications & Technical Data (1979—1982)

Engine power: 75kW – Model series: Dominator – Standard tyres: F:23.1-26/R:12.5-18 – Walkers: 4 – Grain tank size: 2500l – Transmission type: M

Combine Harvesters Claas Dominator 66

Technical specs - Dominator 66 Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
75 kW
Model series
Dominator
Standard tyres
F:23.1-26/R:12.5-18
Walkers
4
Grain tank size
2500 l
Transmission type
M
Weight
9.2 t
Transport length
9.75 m
Transport height
3.7 m
Engine manuf.
Perkins
Engine type
6.3544
Displacement
5.8 l
No. of cylinders
6

More technical details, like: threshing system, rotor Ø, steering, transport width, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model self-propelled motor incl. standard cutting is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Straw chopper
No
Stone Trap
No
Hillside levelling
No
Chaff spreader
No
Loss monitoring
No
Rollover protection
No
All-wheel drive
No
Aircondition
No

Claas Dominator 66 FAQ

When was the Claas Dominator 66 combine harvester manufactured?

The Claas Dominator 66 was manufactured from 1979 to 1982.

What is the weight of the Claas Dominator 66 combine harvester?

The Claas Dominator 66 has a weight of 9.2 tonnes.

What are the physical dimensions of the Claas Dominator 66 combine harvester?

The Claas Dominator 66 has a transport length of 9.75 meters and a transport height of 3.7 meters.

What is the engine power of the Claas Dominator 66?

The Claas Dominator 66 has an engine power of 75 kW.

What type of transmission does the Claas Dominator 66 have?

The Claas Dominator 66 is equipped with a mechanical power shift transmission.

What are the standard tyre specifications for the Claas Dominator 66 combine harvester?

The Claas Dominator 66 is equipped with standard tyres sized F:23.1-26 for the front and R:12.5-18 for the rear.

What is the grain tank volume capacity of the Claas Dominator 66?

The Claas Dominator 66 has a grain tank volume capacity of 2500 liters.

What is the threshing and separation system of the Claas Dominator 66?

The Claas Dominator 66 uses a threshing and separation system with 4 walkers.

How much is a Claas Dominator 66 Combine Harvester (1979u20131982) worth?

The residual value of the Claas Dominator 66 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
