Austoft 9900 Case IH Austoft 9900 Specifications & Technical Data (2022—2026)

The Case IH Austoft 9900 is a combine harvester manufactured by Case IH since 2022. It has a weight of 17.36 tons and is powered b…

The Case IH Austoft 9900 is a combine harvester manufactured by Case IH since 2022. It has a weight of 17.36 tons and is powered by an engine with a power output of 310 kW. The combine harvester has a transport length of 13.93 meters, a transport width of 3.04 meters, and a transport height of 6.34 meters. It features a rotor with a diameter of 380 mm. Additionally, the machine is equipped with special features such as air conditioning, a cabin, and loss monitoring capabilities.

Combine Harvesters Case IH Austoft 9900
Combine Harvesters Case IH Austoft 9900
Combine Harvesters Case IH Austoft 9900
Combine Harvesters Case IH Austoft 9900
Combine Harvesters Case IH Austoft 9900
Combine Harvesters Case IH Austoft 9900

Technical specs - Austoft 9900 Case IH

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
310 kW
Model series
Austoft
Rotor Ø
380 mm
Weight
17.36 t
Transport length
13.93 m
Transport width
3.04 m
Transport height
6.34 m
Engine manuf.
FPT
Engine type
Cursor 11
Displacement
11.1 l
No. of cylinders
6

More technical details, like: standard tyres, threshing system, walkers, grain tank size, steering, transmission type, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model self-propelled motor incl. standard cutting is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Straw chopper
No
Stone Trap
No
Hillside levelling
No
Chaff spreader
No
Loss monitoring
Yes
Rollover protection
No
All-wheel drive
No
Aircondition
Yes

Download datasheets (PDF)

Case IH Austoft 9900 FAQ

When did production of the Case IH Austoft 9900 start?

The Case IH Austoft 9900, part of the Austoft series, was first produced in 2022.

What is the weight of the Case IH Austoft 9900?

The Case IH Austoft 9900 has a weight of 17.36 tonnes.

What are the transport dimensions of the Case IH Austoft 9900?

The Case IH Austoft 9900 has a transport length of 13.93 meters, a transport width of 3.04 meters, and a transport height of 6.34 meters.

What is the engine power of the Case IH Austoft 9900 combine harvester?

The Case IH Austoft 9900 has an engine power of 310 kW.

What is the rotor diameter of the Case IH Austoft 9900?

The Case IH Austoft 9900 has a rotor diameter of 380 millimeters.

How much is a Case IH Austoft 9900 Combine Harvester (2022u20132025) worth?

The residual value of the Case IH Austoft 9900 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Case IH Austoft 9900 overview

Processing

Hydraulic Flow and Controls

It's a variable hydraulic flow combined with automatic controls that adjust harvesting functions based on operating conditions. It optimizes fuel consumption, prevents "chokings" and automatically acts on two levels. When base cutter and chopper roller pressures return to normal levels, ground speed automatically increases to the previous setting on cruise control.


Cleaning

Suspension System Improvement

New suspension cylinder repositioned further to the front of the harvester making the AutoTracker system even more efficient and the response time to the suspension lift command, improving the machine front grip.


New Windshield Protection

It is foldable and transforms into a platform that allows access to the front of the cabin for cleaning and maintenance.


New Battery Compartment

The battery compartment is now positioned close to the engine box and with easier access through the side platform. This makes battery replacement even easier, reducing machine downtime. There is an external energy source close to the main switch. Complete 12V system provides easier maintenance.


Engine

New Air Circuit

Its components maintain quality of air inside the engine. 45% savings on replacement air filters with the new system.


Diesel Exhaust Fluid Circuit (DEF - Diesel Exhaust Fluid) – Only Tier 3 and above

Components that supply DEF within the engine exhaust system include: Urea Tank (DEF): 70 liters Injection Controllers Filters Tube Urea Level Sensor Injector


Cabin / Operator

Autoguidance afs

System with automatic guidance driven by GPS in the fields increases the operation of the harvest easier even in conditions of interlaced high productivity cane fields, preventing the harvester from traveling over the rows and the ratoons. Reduces operator fatigue, increases productivity and allows you to exploit all the harvester's features.


Benefits

Lower losses Higher Productivity Lower fuel consumption Traffic control Reduced fatigue Easier operation
