Tiger 100 SAME Tiger 100 Specifications & Technical Data (1977—1980)

Engine power: 76.1kW – Back tyres: 18.4-34 – Front tyres: 13.6-24 – Transport length: 3.94m – Transport width: 2.72m – Transport height: 2.73m

4WD Tractors SAME Tiger 100

Technical specs - Tiger 100 SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
76.1 kW
Back tyres
18.4-34
Front tyres
13.6-24
Transport length
3.94 m
Transport width
2.72 m
Transport height
2.73 m
Travel speed
24.1 km/h
Transmission
12/3
Transmission type
m
Weight
4.04 t
three point category
2
Engine manuf.
SAME
Engine type
1055L
Displacement
5.2 l
Revolutions at max torque
1450 rpm
Max. torque
370 Nm
No. of cylinders
5
Cylinder bore x stroke
105x120 mm

More technical details, like: model series, control unit, steering, dimension lxwxh, emission level are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
No

SAME Tiger 100 FAQ

When was the SAME Tiger 100 manufactured?

The SAME Tiger 100 was manufactured from 1977 to 1980.

What is the weight of the SAME Tiger 100 tractor?

The SAME Tiger 100 tractor weighs 4.04 tonnes.

What are the physical dimensions of the SAME Tiger 100 tractor?

The SAME Tiger 100 tractor has a transport length of 3.94 meters, a transport width of 2.72 meters, and a transport height of 2.73 meters.

What is the engine power of the SAME Tiger 100?

The SAME Tiger 100 has an engine power of 76.1 kW.

What is the travel speed of the SAME Tiger 100?

The SAME Tiger 100 has a travel speed of 24.1 km/h.

What type of transmission does the SAME Tiger 100 have?

The SAME Tiger 100 is equipped with a mechanical transmission.

What are the wheel and tyre specifications of the SAME Tiger 100?

The SAME Tiger 100 has front tyres sized 13.6-24 and back tyres sized 18.4-34.

What is the three-point hitch category of the SAME Tiger 100?

The SAME Tiger 100 has a category 2 three-point hitch.

How much is a SAME Tiger 100 4WD Tractor (1977u20131980) worth?

The residual value of the SAME Tiger 100 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
