Iron 100 SAME Iron 100 Specifications & Technical Data (2009—2013)

The SAME Iron 100 is a 4-wheel drive tractor manufactured by SAME from 2009 to 2013. It has a weight of 4.44 tons and is powered b…

The SAME Iron 100 is a 4-wheel drive tractor manufactured by SAME from 2009 to 2013. It has a weight of 4.44 tons and is powered by an engine with a capacity of 73 kW. The tractor has a transport length of 4.14 meters and can travel at a speed of 40 km/h. It has a transport width of 2.48 meters and a transport height of 2.66 meters. The tractor is equipped with special equipment such as air conditioning, a cabin, and an ISO Bus.

4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100
4WD Tractors SAME Iron 100

Technical specs - Iron 100 SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
73 kW
Model series
Iron
Back tyres
540/65 R 38
Front tyres
540/65 R 24
Transport length
4.14 m
Transport width
2.48 m
Transport height
2.66 m
Travel speed
40 km/h
Transmission
24/8
Weight
4.44 t
Control unit
-/3 ew/dw
Engine manuf.
Deutz
Engine type
TCD2012 L04 2V

More technical details, like: transmission type, steering, three point category, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
Yes
Aircondition
Yes

Download datasheets (PDF)

SAME Iron 100 FAQ

When was the SAME Iron 100 manufactured?

The SAME Iron 100 was manufactured from 2009 to 2013.

What is the weight of the SAME Iron 100?

The SAME Iron 100 has a weight of 4.44 tonnes.

What are the physical dimensions of the SAME Iron 100 tractor?

The SAME Iron 100 tractor has a transport length of 4.14 meters, a transport width of 2.48 meters, and a transport height of 2.66 meters.

What is the engine power of the SAME Iron 100?

The SAME Iron 100 has an engine power of 73 kW.

What is the travel speed of the SAME Iron 100?

The SAME Iron 100 has a travel speed of 40 km/h.

What are the wheel and tyre specifications of the SAME Iron 100?

The SAME Iron 100 has front tyres sized 540/65 R 24 and back tyres sized 540/65 R 38.

How much is a SAME Iron 100 4WD Tractor (2009u20132013) worth?

The residual value of the SAME Iron 100 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

SAME Iron 100 overview

Engine & Transmission

Engines: a generation of winners

Deutz Common Rail (DCR), Exhaust Gas Recirculation system (EGR), turbo with intercooler, electronic fuel injection, dual liquid/oil cooling system and fuel cooler, for improved overall combustion efficiency. These are just some of the key features offered in the new DEUTZ 2012 series TIER III engines, installed in IRON machines.


Engine Features

In addition, the engine features an efficient air cleaning system of “cross flow” design utilizing a layered structure of nanofibre elements, guaranteeing effective filtration of contaminants down to particle sizes of 2 microns. Similarly, the engine is equipped with a technologically innovative cooling system: five radiator and cooler units are arranged in series (engine coolant, transmission oil, diesel fuel, intercooler and aircon condenser), so as to maximize the exposure of the cooling surfaces to air while keeping the overall dimensions of the assembly to a minimum. An exclusive hinged mounting system allows the radiators to pivot outwards for easy cleaning and maintenance.


Cabin & Accessories

Equipment Features

with the S.D.S. function can be viewed as easy-to-read icons in a dedicated display on the instrument panel. Secondary lift and PTO controls mounted on the rear fenders facilitate the operation of hitching and unhitching implements. In short, quality and safety of work are guaranteed - with no compromises. This already superior equipment package can be enhanced further with the addition of front linkage with double acting cylinders, rated capacity 3200 kg.
