Frutteto CVT 90 SAME Frutteto CVT 90 Specifications & Technical Data (2018—2023)

The SAME Frutteto CVT 90 is a 4-wheel drive tractor manufactured by SAME since 2018. It has a weight of 3.6 tons and is powered by…

The SAME Frutteto CVT 90 is a 4-wheel drive tractor manufactured by SAME since 2018. It has a weight of 3.6 tons and is powered by an engine with a capacity of 65 kW. The tractor has a transport length of 3.718 meters and can travel at a speed of 40 km/h. It has a transport width of 1.588 meters and a transport height of 2.445 meters. The tractor is equipped with special equipment such as air conditioning and a cabin.

Frutteto CVT 90

Years of manufacture: 2018—2023

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Frutteto CVT 90 SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 65 kW

Model series: Fruttero

Back tyres: 380/70 R24

Front tyres: 280/70 R16

Transport length: 3.718 m

Transport width: 1.588 m

Transport height: 2.445 m

Travel speed: 40 km/h

Transmission type: stfl.

Weight: 3.6 t

Control unit: -/3 ew/dw

Steering: h

Engine manuf.: SDF

Engine type: FARMotion

Displacement: 2.887 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 3

Emission level: III B (Tier 4 i)

More technical details, like: transmission, three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: No
Aircondition: Yes

Download datasheets (PDF)

SAME Frutteto CVT 90 FAQ

When was the SAME Frutteto CVT 90 manufactured and what is its model series?

The SAME Frutteto CVT 90 has been produced since 2018 and belongs to the Fruttero model series.

What is the weight of the SAME Frutteto CVT 90?

The SAME Frutteto CVT 90 has a weight of 3.6 tonnes.

What are the physical dimensions of the SAME Frutteto CVT 90?

The SAME Frutteto CVT 90 has a transport length of 3.72 meters, a transport width of 1.59 meters, and a transport height of 2.45 meters.

What is the engine power of the SAME Frutteto CVT 90?

The SAME Frutteto CVT 90 has an engine power of 65 kW.

What is the travel speed of the SAME Frutteto CVT 90?

The SAME Frutteto CVT 90 has a travel speed of 40 km/h.

What type of transmission does the SAME Frutteto CVT 90 have?

The SAME Frutteto CVT 90 is equipped with a continuously variable transmission (CVT).

What type of steering does the SAME Frutteto CVT 90 have for maneuverability?

The SAME Frutteto CVT 90 features hydraulic steering for maneuverability.

What are the wheel and tyre specifications of the SAME Frutteto CVT 90?

The SAME Frutteto CVT 90 has front tyres sized 280/70 R16 and back tyres sized 380/70 R24.

How much is a SAME Frutteto CVT 90 4WD Tractor (2018u20132025) worth?

The residual value of the SAME Frutteto CVT 90 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

SAME Frutteto CVT 90 overview

Engine & Transmission

Transmission Features

Cruise-on: the vehicle accelerates to the set speed, even from a standstill. Cruise-off: the tractor stops and remains stationary (even on a gradient), held in position by the PowerZero function. What could be easier? The new CVT transmission also features a groundspeed PTO mode, which is particularly useful for working with a driven axle trailer. The ergonomic joystick makes controlling the transmission extremely intuitive, with all the main functions operated from fingertip controls. The user programmable function buttons may be used to offer duplicated reverse shuttle control on the MaxCom joystick. A dedicated dial lets the operator select from a variety of different engine management modes ranging from “Eco”, which minimises fuel consumption, to “Power”, which maximises tractor performance. The control unit software features three different operating modes: 1. Manual: with the throttle pedal used to control engine speed and the multifunction joystick used to adjust groundspeed, the tractor behaves essentially like a machine with a mechanical gearbox, but with the smoothness typical of a CVT transmission. Holding the joystick forward or backwards (when driving in reverse or decelerating) produces continuous acceleration or deceleration, whereas pushing the joystick briefly alters the speed in intervals of 0.1Km/h between 0 and 15Km/h, and in intervals of 1Km/h at higher speeds. 2. PTO: This mode is selected automatically when the PTO is engaged, and maintains a stable PTO speed independently of tractor speed, which the driver can continue to vary as required using the accelerator pedal. This functionality overcomes the major limitation of conventional mechanical transmissions, where, at a given groundspeed, the available PTO torque is linked inseparably with the torque produced by the engine at that specific engine speed, and no change in available PTO torque is possible without changing gear. 3. Automatic: This is the recommended mode for traction applications in the field and transporting. The tractor accelerates to the preset speed when the accelerator is pressed, after which the electronic control unit maintains this speed by automatically controlling the engine in relation to load.

Pto

Confirming the versatility of the SAME Frutteto CVT family, these tractors are equipped as standard with a progressively engaged, electrohydraulically controlled PTO with three different operating modes - with the standard 540rpm mode plus 1000rpm and 540ECO modes. All configurations are equipped as standard with the Auto PTO function, which automatically engages and disengages the PTO in relation to the position of the implement hitched to the 3-point linkage, while a transmission-synchronised groundspeed mode is available as an option. An interchangeable splined output shaft and a 1000rpm front PTO are also available as options.

Axle

ActiveDrive Control Software

The ActiveDrive control software includes anti-dive and anti-roll functions as standard. Specifically, anti-dive increases braking safety by countering sudden front suspension compression and the subsequent shift in load towards the front axle. This ensures that correct weight distribution over the four wheels is maintained even under hard braking, reducing stopping distances. Lubricated with transmission oil, the on-board brakes continue to deliver superlative stopping performance even after prolonged use. The anti-roll function, on the other hand, automatically adjusts the stiffness of the suspension system in relation to steering angle and ground speed, improving grip and stability both on the road and in the field.

Suspension and Traction Features

Suspension of the outer wheel relative to the inner wheel when cornering limits roll and improves vehicle body control. Additionally, four wheel drive, selected automatically by the Auto 4WD function, and the electrohydraulically operated 100% lockable front and rear differentials ensure maximum traction in all situations. The optional disc type rear differential lock may be engaged and disengaged progressively for better traction and stability. Four wheel braking is standard.
