Fortis 190 Infinity SAME Fortis 190 Infinity Specifications & Technical Data (2015—2017)

The SAME Fortis 190 Infinity is a 4-wheel drive tractor manufactured from 2015 to 2017. It has a weight of 7.1 tons and is powered…

The SAME Fortis 190 Infinity is a 4-wheel drive tractor manufactured from 2015 to 2017. It has a weight of 7.1 tons and is powered by an engine with a capacity of 143 kW. The tractor has a transport length of 4.81 meters and can travel at a speed of 50 km/h. It has a transport width of 2.54 meters and a transport height of 3.13 meters. The tractor is equipped with 4 control units and comes with special equipment such as air brakes, air conditioning, and a cabin.

Fortis 190 Infinity

Years of manufacture: 2015—2017

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Fortis 190 Infinity SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 143 kW

Model series: Fortis

Back tyres: 650/65 R38

Front tyres: 540/65 R28

Transport length: 4.81 m

Transport width: 2.54 m

Transport height: 3.13 m

Travel speed: 50 km/h

Transmission: 40/40

Transmission type: LS

Weight: 7.1 t

Control unit: 4 ew/dw

Engine manuf.: Deutz

Engine type: TCD6.1 L06

Displacement: 6.057 l

Revolutions at max torque: 2000 rpm

No. of cylinders: 6

Emission level: Tier 4 i

More technical details, like: steering, three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: Yes
ISO Bus: No
Aircondition: Yes

SAME Fortis 190 Infinity FAQ

When was the SAME Fortis 190 Infinity manufactured?

The SAME Fortis 190 Infinity was manufactured from 2015 to 2017.

What is the weight of the SAME Fortis 190 Infinity?

The SAME Fortis 190 Infinity has a weight of 7.1 tonnes.

What are the physical dimensions of the SAME Fortis 190 Infinity tractor?

The SAME Fortis 190 Infinity tractor has a transport length of 4.81 meters, a transport width of 2.54 meters, and a transport height of 3.13 meters.

What is the engine power of the SAME Fortis 190 Infinity?

The SAME Fortis 190 Infinity has an engine power of 143 kW.

What is the travel speed of the SAME Fortis 190 Infinity?

The SAME Fortis 190 Infinity has a travel speed of 50 km/h.

What are the drivetrain and propulsion system specifications of the SAME Fortis 190 Infinity?

The SAME Fortis 190 Infinity has a powershift transmission with 40 forward speeds and 40 reverse speeds.

What are the wheel and tyre specifications of the SAME Fortis 190 Infinity?

The SAME Fortis 190 Infinity has front tyres sized 540/65 R28 and back tyres sized 650/65 R38.

How much is a SAME Fortis 190 Infinity 4WD Tractor (2015u20132017) worth?

The residual value of the SAME Fortis 190 Infinity depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
