Explorer 90 MD SAME Explorer 90 MD Specifications & Technical Data (2015—2019)

The SAME Explorer 90 MD is a 4 wheel drive tractor manufactured from 2015 to 2019. It has a weight of 3.86 tons and is equipped wi…

The SAME Explorer 90 MD is a 4 wheel drive tractor manufactured from 2015 to 2019. It has a weight of 3.86 tons and is equipped with a cabin. The tractor is powered by an engine with a power output of 65 kW. It has a transport length of 4.13 meters and a travel speed of 40 km/h. The transport width is 2.365 meters and the transport height is 2.702 meters.

Explorer 90 MD

Years of manufacture: 2015—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Explorer 90 MD SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 65 kW

Model series: Explorer

Back tyres: 16.9 R34

Front tyres: 14.9 R24

Transport length: 4.13 m

Transport width: 2.365 m

Transport height: 2.702 m

Travel speed: 40 km/h

Transmission: 20/20

Transmission type: m

Weight: 3.86 t

Control unit: -/2 ew/dw

Steering: h

Engine manuf.: SDF

Engine type: FARMotion

Displacement: 2.887 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 3

Emission level: Tier 4 f

More technical details, like: three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: No
Aircondition: No

Download datasheets (PDF)

SAME Explorer 90 MD FAQ

When was the SAME Explorer 90 MD produced?

The SAME Explorer 90 MD was produced from 2015 to 2019.

What is the weight of the SAME Explorer 90 MD?

The SAME Explorer 90 MD has a weight of 3.86 tonnes.

What are the physical dimensions of the SAME Explorer 90 MD tractor?

The SAME Explorer 90 MD tractor has a transport length of 4.13 meters, a transport width of 2.37 meters, and a transport height of 2.7 meters.

What is the engine power of the SAME Explorer 90 MD?

The SAME Explorer 90 MD has an engine power of 65 kW.

What is the travel speed of the SAME Explorer 90 MD?

The SAME Explorer 90 MD has a travel speed of 40 km/h.

What are the drivetrain and propulsion system specifications of the SAME Explorer 90 MD?

The SAME Explorer 90 MD has a mechanical transmission with 20 forward speeds and 20 reverse speeds.

What are the maneuverability specifications of the SAME Explorer 90 MD?

The SAME Explorer 90 MD has hydraulic steering.

What are the wheel and tyre specifications of the SAME Explorer 90 MD?

The SAME Explorer 90 MD has front tyres sized 14.9 R24 and back tyres sized 16.9 R34.

How much is a SAME Explorer 90 MD 4WD Tractor (2015u20132019) worth?

The residual value of the SAME Explorer 90 MD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
