Explorer 90 LD SAME Explorer 90 LD Specifications & Technical Data (2019—2020)

The SAME Explorer 90 LD is a 2 Wheel-Drive Tractor manufactured from 2019 to 2020. It has a weight of 3.62 tons, an engine power o…

The SAME Explorer 90 LD is a 2 Wheel-Drive Tractor manufactured from 2019 to 2020. It has a weight of 3.62 tons, an engine power of 65 kW, and a travel speed of 30 km/h. It has a transport length of 4.1 m, a transport width of 2.341 m, and a transport height of 2.6 m. It is equipped with a 2 control unit (ew/dw) and a cabin as special equipment.

Explorer 90 LD

Years of manufacture: 2019—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Explorer 90 LD SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 65 kW

Model series: Explorer

Back tyres: 480/70 R30

Front tyres: 7.50-18

Transport length: 4.1 m

Transport width: 2.341 m

Transport height: 2.6 m

Travel speed: 30 km/h

Transmission: 40/40

Transmission type: m

Weight: 3.62 t

Control unit: 2 ew/dw

Steering: m

Engine manuf.: SDF

Engine type: FARMotion

Displacement: 2.887 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 3

Emission level: III B

More technical details, like: three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: No
Aircondition: No

Download datasheets (PDF)

SAME Explorer 90 LD FAQ

When was the SAME Explorer 90 LD manufactured?

The SAME Explorer 90 LD, part of the Explorer series, was manufactured from 2019 to 2020.

What is the weight of the SAME Explorer 90 LD?

The SAME Explorer 90 LD has a weight of 3.62 tonnes.

What are the physical dimensions of the SAME Explorer 90 LD tractor?

The SAME Explorer 90 LD tractor has a transport length of 4.1 meters, a transport width of 2.34 meters, and a transport height of 2.6 meters.

What is the engine power of the SAME Explorer 90 LD?

The SAME Explorer 90 LD has an engine power of 65 kW.

What is the travel speed of the SAME Explorer 90 LD?

The SAME Explorer 90 LD has a travel speed of 30 km/h.

What are the drivetrain and propulsion system specifications of the SAME Explorer 90 LD?

The SAME Explorer 90 LD has a mechanical transmission with 40 forward speeds and 40 reverse speeds.

What type of steering does the SAME Explorer 90 LD have?

The SAME Explorer 90 LD has mechanical steering.

What are the wheel and tyre specifications of the SAME Explorer 90 LD?

The SAME Explorer 90 LD has front tyres sized 7.50-18 and back tyres sized 480/70 R30.

How much is a SAME Explorer 90 LD 4WD Tractor (2019u20132020) worth?

The residual value of the SAME Explorer 90 LD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
