Explorer 90.4 DT MD LS SAME Explorer 90.4 DT MD LS Specifications & Technical Data (2015—2016)

The SAME Explorer 90.4 DT MD LS is a 4-wheel drive tractor manufactured from 2015 to 2016. It has a weight of 4.2 tons and is powe…

The SAME Explorer 90.4 DT MD LS is a 4-wheel drive tractor manufactured from 2015 to 2016. It has a weight of 4.2 tons and is powered by an engine with a capacity of 65 kW. The tractor has a transport length of 4.314 meters and can travel at a speed of 40 km/h. It has a transport width of 2.609 meters and a transport height of 1.982 meters. The tractor is equipped with 2 control units and comes with special equipment such as a cabin.

4WD Tractors SAME Explorer 90.4 DT MD LS

Technical specs - Explorer 90.4 DT MD LS SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
65 kW
Model series
Explorer
Back tyres
16.9 R 34
Front tyres
14.9 R 24
Transport length
4.314 m
Transport width
2.609 m
Transport height
1.982 m
Travel speed
40 km/h
Transmission
20/20
Transmission type
LS
Weight
4.2 t
Control unit
2 ew/dw
Steering
h
Engine manuf.
SDF
Engine type
FARMotion
Displacement
3.849 l
Revolutions at max torque
2200 rpm
No. of cylinders
4
Emission level
III B (Tier 4 i)

More technical details, like: three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
No

SAME Explorer 90.4 DT MD LS FAQ

When was the SAME Explorer 90.4 DT MD LS manufactured?

The SAME Explorer 90.4 DT MD LS was produced from 2015 to 2016 as part of the Explorer series.

What is the weight of the SAME Explorer 90.4 DT MD LS?

The SAME Explorer 90.4 DT MD LS weighs 4.2 tonnes.

What are the physical dimensions of the SAME Explorer 90.4 DT MD LS?

The SAME Explorer 90.4 DT MD LS has a transport length of 4.31 meters, a transport width of 2.61 meters, and a transport height of 1.98 meters.

What is the engine power of the SAME Explorer 90.4 DT MD LS?

The SAME Explorer 90.4 DT MD LS has an engine power of 65 kW.

What is the travel speed of the SAME Explorer 90.4 DT MD LS?

The SAME Explorer 90.4 DT MD LS has a travel speed of 40 km/h.

What are the drivetrain and propulsion system specifications of the SAME Explorer 90.4 DT MD LS?

The SAME Explorer 90.4 DT MD LS features a powershift transmission with 20 forward speeds and 20 reverse speeds.

What type of steering does the SAME Explorer 90.4 DT MD LS have?

The SAME Explorer 90.4 DT MD LS is equipped with hydraulic steering.

What are the wheel and tyre specifications of the SAME Explorer 90.4 DT MD LS?

The SAME Explorer 90.4 DT MD LS has front tyres sized 14.9 R 24 and back tyres sized 16.9 R 34.

How much is a SAME Explorer 90.4 DT MD LS 4WD Tractor (2015u20132016) worth?

The residual value of the SAME Explorer 90.4 DT MD LS depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
