Audax 220 ST SAME Audax 220 ST Specifications & Technical Data (2014—2017)

The SAME Audax 220 ST is a 4-wheel drive tractor manufactured by SAME from 2014 to 2017. It has a weight of 8.25 tons and is power…

The SAME Audax 220 ST is a 4-wheel drive tractor manufactured by SAME from 2014 to 2017. It has a weight of 8.25 tons and is powered by an engine with a power output of 157 kW. The tractor has a transport length of 5.01 meters and can travel at a speed of 50 km/h. It has a transport width of 2.55 meters and a transport height of 3.15 meters. The tractor is equipped with a 4-control unit and special features include air brakes, air conditioning, and a cabin.

4WD Tractors SAME Audax 220 ST

Technical specs - Audax 220 ST SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
157 kW
Model series
Audax
Back tyres
650/65 R42
Front tyres
540/65 R34
Transport length
5.01 m
Transport width
2.55 m
Transport height
3.15 m
Travel speed
50 km/h
Transmission
33/33
Weight
8.25 t
Control unit
4 ew/dw
Engine manuf.
Deutz
Engine type
TCD6.1 L06
Displacement
6.057 l
Revolutions at max torque
2100 rpm
No. of cylinders
6
Emission level
Tier 4 i

More technical details, like: transmission type, steering, three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
Yes
ISO Bus
No
Aircondition
Yes

SAME Audax 220 ST FAQ

When was the SAME Audax 220 ST manufactured?

The SAME Audax 220 ST was manufactured from 2014 to 2017.

What is the weight of the SAME Audax 220 ST?

The SAME Audax 220 ST has a weight of 8.25 tonnes.

What are the physical dimensions of the SAME Audax 220 ST tractor?

The SAME Audax 220 ST tractor has a transport length of 5.01 meters, a transport width of 2.55 meters, and a transport height of 3.15 meters.

What is the engine power of the SAME Audax 220 ST?

The SAME Audax 220 ST has an engine power of 157 kW.

What is the travel speed of the SAME Audax 220 ST?

The SAME Audax 220 ST has a travel speed of 50 km/h.

What are the transmission speeds for the SAME Audax 220 ST?

The SAME Audax 220 ST has a transmission with 33 forward speeds and 33 reverse speeds.

What are the wheel and tyre specifications of the SAME Audax 220 ST?

The SAME Audax 220 ST has front tyres sized 540/65 R34 and back tyres sized 650/65 R42.

How much is a SAME Audax 220 ST 4WD Tractor (2014u20132017) worth?

The residual value of the SAME Audax 220 ST depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
