Quantum 80 CL Case IH Quantum 80 CL Specifications & Technical Data (2017—2021)

The Case IH Quantum 80 CL is a 4-wheel drive tractor manufactured by Case IH from 2017 to 2021. It has a weight of 2.832 tons and …

The Case IH Quantum 80 CL is a 4-wheel drive tractor manufactured by Case IH from 2017 to 2021. It has a weight of 2.832 tons and is powered by an engine with a capacity of 55 kW. The tractor can travel at a speed of 40 km/h and has a transport width of 1.44 meters and a transport height of 2.45 meters. It is equipped with special features such as air conditioning and a cabin.

Quantum 80 CL

Years of manufacture: 2017—2021

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - Quantum 80 CL Case IH

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 55 kW

Model series: Quantum

Back tyres: 480/70 R28

Front tyres: 360/70 R20

Transport width: 1.44 m

Transport height: 2.45 m

Travel speed: 40 km/h

Transmission: 16/16

Transmission type: m

Weight: 2.832 t

Control unit: -/4 ew/dw

Steering: h

three point category: 2

Engine manuf.: FPT

Engine type: F5C

Displacement: 3.4 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 4

Emission level: IV

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: No
Aircondition: Yes

Download datasheets (PDF)

Case IH Quantum 80 CL FAQ

When was the Case IH Quantum 80 CL produced?

The Case IH Quantum 80 CL was produced from 2017 to 2021.

What is the weight of the Case IH Quantum 80 CL?

The Case IH Quantum 80 CL has a weight of 2.83 tonnes.

What are the physical dimensions of the Case IH Quantum 80 CL?

The Case IH Quantum 80 CL has a transport width of 1.44 meters and a transport height of 2.45 meters.

What is the engine power of the Case IH Quantum 80 CL?

The Case IH Quantum 80 CL has an engine power of 55 kW.

What is the travel speed of the Case IH Quantum 80 CL?

The Case IH Quantum 80 CL has a travel speed of 40 km/h.

What are the drivetrain and transmission specifications of the Case IH Quantum 80 CL?

The Case IH Quantum 80 CL has a mechanical transmission with 16 forward speeds and 16 reverse speeds.

What type of steering does the Case IH Quantum 80 CL have?

The Case IH Quantum 80 CL features hydraulic steering.

What are the wheel and tyre specifications of the Case IH Quantum 80 CL?

The Case IH Quantum 80 CL has front tyres sized 360/70 R20 and back tyres sized 480/70 R28.

What is the three-point hitch category of the Case IH Quantum 80 CL?

The Case IH Quantum 80 CL has a category 2 three-point hitch.

How much is a Case IH Quantum 80 CL 4WD Tractor (2017u20132021) worth?

The residual value of the Case IH Quantum 80 CL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
