CS 80 Pro Case IH CS 80 Pro Specifications & Technical Data (2000—2008)

Engine power: 61kW – Back tyres: 14,9R24 – Front tyres: 18,4R34 – Transport length: 4.2m – Transport width: 2.48m – Transport height: 2.62m

4WD Tractors Case IH CS 80 Pro

Technical specs - CS 80 Pro Case IH

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
61 kW
Back tyres
14,9R24
Front tyres
18,4R34
Transport length
4.2 m
Transport width
2.48 m
Transport height
2.62 m
Travel speed
39.9 km/h
Transmission
16F/8R
Weight
4.15 t
Engine manuf.
Sisu
Engine type
44DT
Displacement
4.4 l
Revolutions at max torque
1400 rpm
Max. torque
310 Nm
No. of cylinders
4
Cylinder bore x stroke
108x120 mm

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
No

Case IH CS 80 Pro FAQ

When was the Case IH CS 80 Pro manufactured?

The Case IH CS 80 Pro was manufactured from 2000 to 2008.

What is the weight of the Case IH CS 80 Pro?

The Case IH CS 80 Pro has a weight of 4.15 tonnes.

What are the physical dimensions of the Case IH CS 80 Pro tractor?

The Case IH CS 80 Pro tractor has a transport length of 4.2 meters, a transport width of 2.48 meters, and a transport height of 2.62 meters.

What is the engine power of the Case IH CS 80 Pro?

The Case IH CS 80 Pro has an engine power of 61 kW.

What is the travel speed of the Case IH CS 80 Pro?

The Case IH CS 80 Pro has a travel speed of 39.9 km/h.

What are the transmission speeds for the Case IH CS 80 Pro?

The Case IH CS 80 Pro has a transmission with 16 forward speeds and 8 reverse speeds.

What are the wheel and tyre specifications of the Case IH CS 80 Pro?

The Case IH CS 80 Pro has front tyres sized 18,4R34 and back tyres sized 14,9R24.

How much is a Case IH CS 80 Pro 4WD Tractor (2000u20132008) worth?

The residual value of the Case IH CS 80 Pro depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
