AL 12 DIN 45 B Marrel AL 12 DIN 45 B Specifications & Technical Data (2014—2026)

Lifting force: 11.768kN – max. hook height: 1.57m – Construction type: S – Max. container length: 5.25m – max. total weight: 19t – Axles: 2

Technical specs - AL 12 DIN 45 B Marrel

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Lifting force
11.768 kN
max. hook height
1.57 m
Construction type
S
Max. container length
5.25 m
max. total weight
19 t
Axles
2
Model series
AL

Basic unit, unmounted K = articulated hook arm, SZA = semi-trailer, KO = combination of articulated hook arm and winch for slip-off/roll-off container, S = thrust hook arm, SK = articulated thrust hook arm, SiloT = silo transporter

Special equipment

telescopic
Yes
with add. articulation
No
3-way tipping device
No
