UTK 500 AL/AL AHT UTK 500 AL/AL Specifications & Technical Data (2006—2026)

Weight: 188kg – Platform length: 1.2m – Platform width: 1.8m – Carr. capacity at distance: 500kg – from rear edge: 500mm – construction type: F/U

Loading platforms AHT UTK 500 AL/AL

Technical specs - UTK 500 AL/AL AHT

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
188 kg
Platform length
1.2 m
Platform width
1.8 m
Carr. capacity at distance
500 kg
from rear edge
500 mm
construction type
F/U
Platform
A

unmounted in standard width Type: S=standard, F= foldable, K=cartridge, P=pendular folding, U=ground clearance for easy access, V= vertical lift

Special equipment

Central lubrication
Yes
central locking
No
low noise
No
GGVS equipped
No

Download datasheets (PDF)

AHT UTK 500 AL/AL overview

Mechanic

Safety First

Cylinders are equipped with mechanical hose-burst valves which are operative during lifting and lowering the platform. The platform will stop immediately if a hose bursts, protecting the operator and goods alike.


Platform

Mounting Pins

The bolts are mounted in DU-bearings. The pins on all-aluminum platforms are mounted in ceramic-coated bearings. Since ceramic is not an electrical conductive material, it avoids corrosion. The pins can be easily removed after years of hard use. All pins are secured with a bracket, and the screws are made of stainless steel.


Control

MHW®-Powerpack

Platform lift is achieved by the compact and fully integrated MHW powerpack in a splash proof aluminum box. Its two-button remote control, for Up and Down operation, is equipped with a cord pull-out protector to prevent electrical shorts and other damage. The control switch prevents unauthorized operation of the tail lift.
