ATK 1000 ST/AL AHT ATK 1000 ST/AL Specifications & Technical Data (2006—2026)

Weight: 247kg – Platform length: 1.15m – Platform width: 2.2m – Carr. capacity at distance: 1000kg – from rear edge: 600mm – construction type: F/S

Loading platforms AHT ATK 1000 ST/AL

Technical specs - ATK 1000 ST/AL AHT

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
247 kg
Platform length
1.15 m
Platform width
2.2 m
Carr. capacity at distance
1000 kg
from rear edge
600 mm
construction type
F/S
Platform
A
Model series
ATK

unmounted in standard width Type: S=standard, F= foldable, K=cartridge, P=pendular folding, U=ground clearance for easy access, V= vertical lift

Special equipment

Central lubrication
No
central locking
No
low noise
Yes
GGVS equipped
No

Download datasheets (PDF)

AHT ATK 1000 ST/AL overview

Mechanic

Safety First

Cylinders are equipped with mechanical hose-burst valves which are operative during lifting and lowering the platform. The platform will stop immediately if a hose bursts, protecting the operator and goods alike.


Platform

Mounting Pins

The bolts are mounted in DU-bearings. The pins on all-aluminum platforms are mounted in ceramic-coated bearings. Since ceramic is not an electrical conductive material, it avoids corrosion. The pins can be easily removed after years of hard use. All pins are secured with a bracket, and the screws are made of stainless steel.


Platform Hinge

The continuous aluminum hinge is guided by a stainless steel rod that has a grease fitting at every section.


Control

MHW®-Powerpack

Platform lift is achieved by the compact and fully integrated MHW powerpack in a splash proof aluminum box. Its two-button remote control, for Up and Down operation, is equipped with a cord pull-out protector to prevent electrical shorts and other damage. The control switch prevents unauthorized operation of the tail lift.
