PK 88002 EH E Palfinger PK 88002 EH E Specifications & Technical Data (2017—2026)

The Palfinger PK 88002 EH E is a truck-mounted loading crane manufactured by Palfinger since 2017. It has a weight of 8.18 tons an…

The Palfinger PK 88002 EH E is a truck-mounted loading crane manufactured by Palfinger since 2017. It has a weight of 8.18 tons and a carrying capacity of 4.35 tons. The load torque is 800.7 kNm, and it has a maximum carrying capacity of 27.2 tons. At its maximum reach of 15.5 meters, it can lift heavy loads. The crane also has a load of additional jib of 1.82 tons. The maximum standard boom length is 15.5 meters. The machine itself has a length of 2.55 meters, a width of 1.915 meters, and a height of 2.47 meters. At its maximum reach of 24.6 meters, it can still perform its functions.

Hydraulic loading cranes Palfinger PK 88002 EH E

Visit Palfinger live at

Technical specs - PK 88002 EH E Palfinger

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
800.7 kNm
machine length
2.55 m
machine width
1.915 m
machine height
2.47 m
max. standard boom
15.5 m
Carrying capacity
4.35 t
at max. reach
15.5 m
Load of additional Jib
1.82 t
Weight
8.18 t
max. carrying capacity
27.2 t
Model series
EH

More technical details, like: at reach, max. hook height, required power are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
No
Electronic load torque limitation
No
Endless pivoting
No
High seat
No
Remote control
No
Adjustable pivoting
No
Articulated boom overstraining
No

Download datasheets (PDF)

Palfinger PK 88002 EH E overview

Palfinger PK 88002 EH E features overview

Functional design

Robust plastic covers protect crane parts against dirt and damage. Better appearance and increased operational comfort – during the entire lifetime.


Lifting

Operator-Friendly Product Design

High value retention due to coating technology Additional applications due to Power Link Plus Maximum utilisation of the working range due to HPSC More lifting power due to E-HPLS


Power Link Plus

With the 15-degree reverse linkage system, you can reach through low door openings and also work inside buildings. Heavy crane work – even in difficult conditions.


Low-maintenance extension system

With sliding elements made of synthetic material and the high-quality KTL coating, this boom system significantly simplifies service performed by the operator. This saves time and money – and protects the environment.


Hpsc

The variable stabiliser positioning of the High Performance Stability Control System makes it possible to utilise the lifting capacity to the maximum. It enables working within tight spaces.


Power Link cable winch

Characterised by low installation height, it is ideal for working inside buildings and transports with the crane boom unfolded. The Comfort Cable Routing reduces setup times to a minimum.


Continuous slewing system

More efficient in operation due to faster loading cycles, since the crane can be slewed over a shorter distance. The crane works more efficiently and faster.


Jib

Coating technology

The KTL coating lays the foundation for a perfect surface protection. Afterwards, the components are either coated in the powder-coating facility or finished with a two-components topcoat. This process ensures high value retention and excellent corrosion protection for the entire life of a crane.


Equipment & Digital

Radio remote control

PALFINGER radio remote controls are equipped with linear lever or cross lever and provide the greatest possible comfort for the operator. All EH models with LED-Display inform the crane operator about the different operating conditions.
