PK 63002 EH D Palfinger PK 63002 EH D Specifications & Technical Data (2017—2026)

The Palfinger PK 63002 EH D is a truck-mounted loading crane manufactured by Palfinger since 2017. It has a weight of 6.096 tons a…

The Palfinger PK 63002 EH D is a truck-mounted loading crane manufactured by Palfinger since 2017. It has a weight of 6.096 tons and a carrying capacity of 3.7 tons. The load torque is 582.7 kNm, and it has a maximum carrying capacity of 20.5 tons. At its maximum reach of 13.6 meters, it can lift heavy loads. The crane has a maximum standard boom length of 13.6 meters. The machine itself has a length of 2.55 meters, a width of 1.705 meters, and a height of 2.45 meters. At a reach of 22.6 meters, it can still perform its functions. It is also capable of carrying an additional jib load of 1.32 tons.

Hydraulic loading cranes Palfinger PK 63002 EH D

Visit Palfinger live at

Technical specs - PK 63002 EH D Palfinger

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
582.7 kNm
machine length
2.55 m
machine width
1.705 m
machine height
2.45 m
max. standard boom
13.6 m
Carrying capacity
3.7 t
at max. reach
13.6 m
Load of additional Jib
1.32 t
Weight
6.096 t
max. carrying capacity
20.5 t
Model series
EH

More technical details, like: at reach, max. hook height, required power are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
No
Electronic load torque limitation
No
Endless pivoting
No
High seat
No
Remote control
No
Adjustable pivoting
No
Articulated boom overstraining
No

Download datasheets (PDF)

Palfinger PK 63002 EH D overview

Palfinger PK 63002 EH D features overview

Functional design

Robust plastic covers protect crane parts against dirt and damage. Better appearance and increased operational comfort – during the entire lifetime.


Lifting

Power Link Plus

With the 15-degree reverse linkage system, you can reach through low door openings and also work inside buildings. Heavy crane work – even in difficult conditions.


Low-maintenance extension system

With sliding elements made of synthetic material and the high-quality KTL coating, this boom system significantly simplifies service performed by the operator. This saves time and money – and protects the environment.


High Performance Stability Control System

The variable stabiliser positioning of the High Performance Stability Control System makes it possible to utilise the lifting capacity to the maximum. It enables working within tight spaces.


Power Link cable winch

Characterised by low installation height, it is ideal for working inside buildings and transports with the crane boom unfolded. The Comfort Cable Routing reduces setup times to a minimum.


Continuous slewing system

More efficient in operation due to faster loading cycles, since the crane can be slewed over a shorter distance. The crane works more efficiently and faster.


Jib

Coating technology

The KTL coating lays the foundation for a perfect surface protection. Afterwards, the components are either coated in the powder-coating facility or finished with a two-components topcoat. This process ensures high value retention and excellent corrosion protection for the entire life of a crane.


Equipment & Digital

Radio remote control

PALFINGER radio remote controls are equipped with linear lever or cross lever and provide the greatest possible comfort for the operator. All EH models with LED-Display inform the crane operator about the different operating conditions.
