    HMF 610-K3 Specifications & Technical Data (2017-2019)

    Rate this machine now!

    HMF is the manufacturer of the hydraulic loading crane model 610-K3. Find and download detailed specs and data sheets for this mac... Read more

    HMF is the manufacturer of the hydraulic loading crane model 610-K3. Find and download detailed specs and data sheets for this machine here.

    The 610-K3 is categorised in the smallest machine segment in the hydraulic loading crane category. This model is 2.1m long and 0.661m wide. The max. Standard boom of this HMF model is 8.9m. The load torque of this model is 50kNm.

    High seat, Adjustable pivoting and Endless pivoting are not provided on this model as of 2018. More detailed specifications and machine descriptions can be found in the original HMF 610-K3 specs data sheet. Available in German, French, Spanish and English, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    Manufacturing of this model is still ongoing.

    HMF currently produces 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm - the most visited on LECTURA Specs are 260-T2, 6020-K6 , 340-K2 . Ranked in the LECTURA index at #2934, this 610-K3 hydraulic loading crane has models that date from 2017 to 2018. Want more detailed specifications? Download the latest HMF 610-K3 specs data sheet on LECTURA Specs today!

    Technical specs - 610-K3 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 50 kNm
    • machine length 2.1 m
    • machine width 0.661 m
    • machine height 1.84 m
    • max. standard boom 8.9 m
    • Carrying capacity 0.4 t
    • at max. reach 10.8 m
    • Weight 0.865 t
    • Load of additional Jib ###
    • max. carrying capacity ###
    • at reach ###
    • max. hook height ###
    • Required power ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
