1430-K3 HMF 1430-K3 Specifications & Technical Data (2008—2021)

The HMF 1430-K3 is a truck-mounted loading crane manufactured by HMF from 2008 to 2021. It has a weight of 1.79 tons and a carryin…

The HMF 1430-K3 is a truck-mounted loading crane manufactured by HMF from 2008 to 2021. It has a weight of 1.79 tons and a carrying capacity of 1.11 tons. The crane requires 25 kW of power and has a load torque of 124 kNm. Its maximum carrying capacity is 2.87 tons and it can reach up to 10.4 meters. The crane's standard boom length is also 10.4 meters. The machine itself has a length of 2.5 meters, a width of 0.825 meters, and a height of 2.245 meters. At a reach of 4.4 meters, the crane is equipped with adjustable pivoting, electronic load torque limitation, and hydraulic brace support.

Hydraulic loading cranes HMF 1430-K3

Technical specs - 1430-K3 HMF

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
124 kNm
machine length
2.5 m
machine width
0.825 m
machine height
2.245 m
max. standard boom
10.4 m
Carrying capacity
1.11 t
at max. reach
10.4 m
Weight
1.79 t
max. carrying capacity
2.87 t
at reach
4.4 m
Required power
25 kW
Model series
K

More technical details, like: load of additional jib, max. hook height are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
Yes
Electronic load torque limitation
Yes
Endless pivoting
No
High seat
No
Remote control
No
Adjustable pivoting
Yes
Articulated boom overstraining
No
