    HMF 1420-K4 Specifications & Technical Data (2016-2021)

    Rate this machine now!

    HMF is the manufacturer of the hydraulic loading crane model 1420-K4. Find and download detailed specs and data sheets for this ma... Read more

    HMF is the manufacturer of the hydraulic loading crane model 1420-K4. Find and download detailed specs and data sheets for this machine here.

    The HMF 1420-K4 can be grouped in the smallest machine segment in the hydraulic loading crane category. This model is 2.5m long and 0.825m wide. To be able to lift loads, the 1420-K4 crane is equipped with a 12.7m-long boom. The HMF 1420-K4 can carry up to 2.72t. This model is constructed to deliever a load torque of 120kNm.

    It has been sold without Remote control, Adjustable pivoting and Endless pivoting as of 2018. More detailed specifications and machine descriptions can be found in the original HMF 1420-K4 specs data sheet. Available in Spanish, English, German and French, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    Manufacturing of this model is still ongoing.

    At present, 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm are produced by HMF. Of these, 260-T2, 340-K2 and also 6020-K6 are the most frequently visited on LECTURA Specs. This 1420-K4 hydraulic loading crane, which was produced between 2016 and 2018 ranks in the LECTURA index at #3329. Want more detailed specifications? Download the latest HMF 1420-K4 specs data sheet on LECTURA Specs today!

    Technical specs - 1420-K4 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 120 kNm
    • machine length 2.5 m
    • machine width 0.825 m
    • machine height 2.245 m
    • max. standard boom 12.7 m
    • Carrying capacity 0.8 t
    • at max. reach 12.7 m
    • Weight 1.975 t
    • max. carrying capacity 2.72 t
    • at reach 4.5 m
    • Required power 25-38 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
