    HMF 1230-K2 Specifications & Technical Data (2016-2021)

    Rate this machine now!

    HMF is the manufacturer of the hydraulic loading crane model 1230-K2. Find and download detailed specs and data sheets for this ma... Read more

    HMF is the manufacturer of the hydraulic loading crane model 1230-K2. Find and download detailed specs and data sheets for this machine here.

    The 1230-K2 is categorised in the smallest machine segment in the hydraulic loading crane category. Dimensions of 1230-K2 model are 2.5m length and 0.747m width. 8.2m is the maximum length of the standard boom for the 1230-K2 crane. The 1230-K2 Hydraulic Loading Crane has a maximum capacity of 2.73t. This model is constructed to deliever a load torque of 113kNm.

    Hydr. Brace support, Remote control and Endless pivoting are not provided on this model as of 2018. Get the original HMF 1230-K2 datasheet for even more detailed specifications and machine details. Available in Spanish, French, German and English, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    The production of the 1230-K2 is still going on.

    The most commonly viewed HMF models of this type on LECTURA Specs are the 6020-K6 , 260-T2 and 340-K2 , and 429 other hydraulic loading cranes are currently available, ranging from 5kNm up to 756kNm. This 1230-K2 hydraulic loading crane, which was produced between 2016 and 2018 ranks in the LECTURA index at #3550. Want more detailed specifications? Download the latest HMF 1230-K2 specs data sheet on LECTURA Specs today!

    Technical specs - 1230-K2 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 113 kNm
    • machine length 2.5 m
    • machine width 0.747 m
    • machine height 2.135 m
    • max. standard boom 8.2 m
    • Carrying capacity 1.37 t
    • at max. reach 8.2 m
    • Weight 1.205 t
    • max. carrying capacity 2.73 t
    • at reach 4.2 m
    • Required power 20 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
